ALL LED AMKR032AL/40 Midi LED Marker Light – 4000K Brushed Aluminium
The ALL LED AMKR032AL/40 Midi LED Marker Light is a compact 1W recessed architectural fitting with a contemporary matt brushed aluminium finish and 4000K neutral white illumination. Designed for floor, wall and ceiling installations, it combines IP65 protection, CREE LED technology and a halogen-style diffusing lens to provide discreet accent lighting for residential and commercial environments.
With a 32mm cut-out diameter and compact 37mm overall size, this marker light offers an unobtrusive way to illuminate stairways, corridors, bathrooms and architectural features. The brushed aluminium housing complements contemporary interiors and provides a distinctive metallic finish for decorative lighting installations.
Key Features – ALL LED AMKR032AL/40 Midi LED Marker Light
- 1W energy-efficient recessed LED marker light
- 4000K neutral white colour temperature
- Contemporary matt brushed aluminium finish
- Durable aluminium housing
- IP65 protection against dust and water jets
- 45° beam angle for controlled accent illumination
- Integrated halogen-style diffusing lens
- CREE LED diode technology
- Suitable for recessed floor, wall and ceiling installations
- Suitable for appropriately installed walk-over applications
- 32mm cut-out diameter
- 37mm overall diameter
- Pre-wired with 2m cable
- 350mA constant current operation
- Requires a separately purchased constant current LED driver
- Multiple fittings must be connected in series using a compatible driver
- 50,000-hour rated lifetime
- 3-year manufacturer’s guarantee
4000K Neutral White Lighting with a Brushed Aluminium Finish
The ALL LED AMKR032AL/40 Midi LED Marker Light produces a crisp 4000K neutral white output, making it particularly suitable for modern interiors where clean, balanced lighting is preferred. Unlike warmer 3000K versions, the 4000K output provides a more neutral appearance that works well in bathrooms, corridors, kitchens and contemporary architectural settings.
Its 45° beam angle helps direct illumination towards selected surfaces, architectural details and floor-level features. The integrated halogen-style lens diffuses the LED output, creating a controlled lighting effect suitable for decorative and practical accent lighting.
The matt brushed aluminium finish complements stainless steel accessories, modern architectural materials and neutral interior colour schemes. It provides a subtle metallic appearance that can be coordinated with other brushed metal fixtures.
Technical Specifications
| Manufacturer | ALL LED |
|---|---|
| Product Code | AMKR032AL/40 |
| Product Range | Midi Marker Light |
| Power Consumption | 1W |
| Operating Current | 350mA Constant Current |
| Colour Temperature | 4000K Neutral White |
| Housing Finish | Matt Brushed Aluminium |
| Housing Material | Aluminium |
| Beam Angle | 45° |
| Luminous Output | Up to 95lm |
| CRI | >80 |
| IP Rating | IP65 |
| Cut-Out Diameter | 32mm |
| Overall Diameter | 37mm |
| Recess Depth | 37mm |
| Pre-Wired Cable | 2m |
| LED Technology | CREE |
| Operating Temperature | -20°C to +50°C |
| Rated Lifetime | 50,000 Hours |
| Electrical Classification | Class III |
| Certifications | CE, RoHS, ErP |
| Guarantee | 3 Years |
Compact 32mm Recessed Installation
The ALL LED AMKR032AL/40 Midi LED Marker Light is designed for discreet installations where space is limited and the visual appearance of the fitting is important. Its 32mm cut-out and 37mm overall diameter make it suitable for incorporating into appropriate plasterboard, timber and tiled surfaces.
The brushed aluminium bezel creates a neat decorative finish around the recessed light source. Its compact dimensions make the Midi range particularly useful for installation along staircases, within decorative walls and in carefully planned floor-level lighting arrangements.
A 2m pre-wired cable simplifies routing towards the selected constant current driver. Installers should consider cable access, recess depth and driver positioning before completing the installation.
Walk-Over and Outdoor Architectural Lighting
The robust aluminium construction and IP65 protection allow the Midi marker light to be considered for suitable walk-over and outdoor architectural installations. It can be used for discreet lighting along pathways, entrance areas and decorative floor features where the fitting is correctly mounted.
For bathroom applications, its IP65 rating makes it suitable for appropriately assessed Zone 1 and Zone 2 installations, subject to applicable wiring requirements and the manufacturer’s installation instructions.
Outdoor applications should be planned with consideration for drainage, standing water, surface loading and mechanical protection. For locations exposed to vehicle traffic, any required load-bearing mounting accessories and the manufacturer’s drive-over rating must be confirmed separately.
Compatible 350mA Constant Current LED Drivers
The ALL LED AMKR032AL/40 Midi LED Marker Light operates at 350mA constant current and requires a suitable LED driver, sold separately. The fitting must never be connected directly to a 230V mains supply.
Driver selection depends on the number of LED fittings, the combined forward voltage, the driver’s permissible output range and any required dimming functionality. When multiple fittings are connected to one compatible constant current driver, they must be wired in series.
Electrical4Less offers a choice of ALL LED constant current drivers for individual marker lights and larger coordinated lighting installations.
- ALL LED ADRCC350/1-11 – 1–11W non-dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/1-4 – 1–4W dimmable 350mA constant current driver.
- ALL LED ADRCC350ANOTD/2-4 – 2–4W dimmable 350mA Nano driver.
- ALL LED ADRCC350TD/4-9 – 4–9W dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/9-18 – 9–18W dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/12-25 – 12–25W dimmable 350mA constant current driver.
- ALL LED ADRCC12D/100-440MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
- ALL LED ADRCC30D/300-900MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
Explore our ALL LED 350mA mains dimmable LED drivers for additional driver options and suitable control gear.
Important: A driver’s wattage rating alone does not guarantee compatibility. Always verify its output voltage range, minimum load, maximum load and permitted number of LED fittings before installation.
IMPORTANT INSTALLATION INSTRUCTIONS – SERIES WIRING ONLY
WARNING: INCORRECT CONNECTIONS WILL DAMAGE THE LED MARKER LIGHTS!
The ALL LED AMKR032AL/40 Midi LED Marker Light is a 350mA CONSTANT CURRENT fitting and must be connected to a correctly specified constant current LED driver.
MULTIPLE LED FITTINGS MUST BE CONNECTED IN SERIES – NEVER IN PARALLEL.
- Connect the positive (+) output of the LED driver to the positive (+) connection of the first LED fitting.
- Connect the negative (-) connection of the first fitting to the positive (+) connection of the next fitting.
- Continue connecting additional LED fittings in series using the same arrangement.
- Connect the negative (-) connection of the final LED fitting back to the negative (-) output of the driver.
- Never connect the LED fittings directly to a 230V mains supply.
- Never connect or disconnect LED fittings while the driver is energised.
- Complete and inspect all connections before switching on the power supply.
- Observe the correct polarity and ensure every connection is secure.
- Check that the driver’s output voltage and load range support the complete series-connected circuit.
- For adjustable constant current drivers, ensure the output is correctly configured to 350mA before energising the circuit.
DO NOT CONNECT THESE FITTINGS IN PARALLEL. INCORRECT WIRING WILL DAMAGE THE LEDs. ALWAYS COMPLETE CONNECTIONS BEFORE SWITCHING ON THE DRIVER.
Always follow the manufacturer’s installation instructions and the wiring diagram provided with the selected driver. Installation must be carried out by a competent person.
Multiple LED Marker Lights and Dimming Control
The ALL LED AMKR032AL/40 Midi LED Marker Light can be incorporated into coordinated lighting schemes using multiple fittings connected to a correctly rated 350mA constant current driver. This makes it suitable for staircases, corridors, floor-level lighting and decorative architectural features requiring consistent neutral white illumination.
For multiple fitting installations, the total forward voltage of the connected LED markers must fall within the selected driver’s specified output voltage range. All fittings must be connected securely in series before power is applied.
Where dimming functionality is required, compatible drivers can be selected according to the intended control arrangement. Available options include mains dimming, DALI and 1–10V systems, depending on the chosen driver model.
Energy-Efficient 4000K Accent Lighting
With a rated consumption of just 1W, the ALL LED AMKR032AL/40 Midi LED Marker Light offers an energy-efficient solution for decorative lighting installations. Its 4000K neutral white colour temperature creates a balanced lighting appearance, particularly suited to modern bathrooms, staircases and contemporary architectural spaces.
The integrated CREE diode and halogen-style diffusing lens provide controlled light output, while the 45° beam angle directs illumination towards the intended surface or architectural detail.
With a rated lifetime of 50,000 hours, the fitting is well suited to lighting schemes where dependable operation and reduced maintenance requirements are important.
Suitable Applications – ALL LED AMKR032AL/40 Midi LED Marker Light
The compact construction, brushed aluminium finish and IP65 protection make this recessed marker light suitable for a range of residential and commercial lighting applications.
- Bathroom accent lighting in appropriately assessed Zone 1 and Zone 2 locations
- Stairway and step illumination
- Decorative recessed floor lighting
- Corridor and hallway marker lighting
- Contemporary residential architectural lighting
- Commercial interior feature lighting
- Suitable walk-over lighting installations
- Appropriate outdoor architectural lighting locations
- Wall and ceiling accent illumination
- Decorative lighting around entrance areas and architectural features
The ALL LED AMKR032AL/40 Midi LED Marker Light is a practical choice where compact dimensions, a contemporary metallic finish and neutral white illumination are required. Its recessed construction allows the fitting to remain visually discreet while providing functional accent lighting.
Why Choose the ALL LED Midi Marker Light?
For electricians and lighting installers, the ALL LED AMKR032AL/40 Midi LED Marker Light combines a compact 32mm cut-out, low 1W power consumption and a durable brushed aluminium housing. Its 350mA constant current operation provides flexibility for individual fittings and carefully designed multi-light arrangements using compatible drivers.
The combination of IP65 protection, a 50,000-hour rated lifetime, a 3-year manufacturer’s guarantee and a choice of suitable driver configurations makes this fitting an attractive solution for residential and commercial architectural lighting projects.
