ALL LED ALSQ032WH/30 Sloane Classic LED Light – Polar White 3000K
The ALL LED ALSQ032WH/30 Sloane Classic LED Light is a compact 1W recessed fitting designed to provide comfortable low-level illumination in residential and commercial environments. Featuring a Polar White finish, warm 3000K light output and IP65 protection, this architectural LED light is ideal for staircases, hallways, walls and decorative plinth lighting.
Part of the ALL LED Sloane Classic range, this fitting incorporates a frosted glass diffuser that distributes light evenly and helps reduce glare. Its ultra-slim profile makes it particularly suitable for discreet architectural installations where soft illumination and a clean, unobtrusive appearance are important.
Key Features – ALL LED ALSQ032WH/30 Sloane Classic LED Light
- 1W energy-efficient recessed low-level LED light
- 3000K warm white colour temperature
- Contemporary Polar White finish
- Frosted glass diffuser for soft, even illumination
- Anti-glare design for comfortable accent lighting
- IP65 protection against dust and water jets
- Ultra-slim profile for discreet installation
- Suitable for architectural wall and plinth lighting
- Ideal for staircases, hallways and corridors
- Suitable for appropriately assessed indoor and outdoor installations
- 350mA constant current operation
- Dimmable with a compatible dimmable LED driver
- Supplied with a 1-metre pre-wired cable
- Requires a separately purchased constant current LED driver
- Multiple fittings must be connected in series using a compatible driver
3000K Warm White Lighting with a Frosted Glass Diffuser
The ALL LED ALSQ032WH/30 Sloane Classic LED Light produces warm 3000K illumination, creating a welcoming atmosphere for residential and commercial interiors. The warm white output is particularly suitable for living spaces, staircases, hallways and architectural features where softer lighting is preferred.
The integrated frosted glass diffuser spreads light evenly and helps soften the appearance of the LED source. Unlike architectural fittings with clear glass lenses that produce sharply defined beams, the Sloane Classic offers a more diffused lighting effect suited to comfortable low-level illumination.
This makes it useful for installations where decorative lighting should complement the surrounding environment without creating pronounced light patterns or excessive brightness.
Polar White Finish and Contemporary Styling
The Polar White finish allows the Sloane Classic fitting to blend discreetly into white-painted walls, pale decorative panels and modern architectural surfaces.
Its ultra-slim construction minimises the visible appearance of the fitting, making it suitable for interiors where larger wall lights would interrupt the design. The clean white finish also complements contemporary switches, sockets and other white electrical accessories.
For installations requiring several matching fittings, the Polar White finish helps create a coordinated appearance across staircases, corridors and decorative wall arrangements.
Technical Specifications
| Manufacturer | ALL LED |
|---|---|
| Product Code | ALSQ032WH/30 |
| Product Range | Sloane Classic |
| Product Type | Recessed Low-Level LED Light |
| Rated Power | 1W |
| Operating Current | 350mA Constant Current |
| Colour Temperature | 3000K Warm White |
| Finish | Polar White |
| Diffuser | Frosted Glass |
| Light Distribution | Soft, Evenly Distributed Illumination |
| Glare Control | Anti-Glare |
| Ingress Protection | IP65 |
| Mounting | Recessed |
| Profile | Ultra-Slim |
| Pre-Wired Cable | 1 Metre |
| Dimmable | Yes, with Compatible Dimmable LED Driver |
| LED Driver | Required – Sold Separately |
| Multiple Fitting Connection | Series Wiring with Compatible Constant Current Driver |
Discreet Low-Level Lighting for Staircases and Hallways
The ALL LED ALSQ032WH/30 Sloane Classic LED Light is particularly suitable for staircase and hallway installations where soft, supplementary illumination is required without the appearance of conventional wall-mounted luminaires.
When recessed into a suitable wall at low level, the fitting can provide gentle illumination across nearby steps and architectural surfaces. Its frosted diffuser helps create a smooth lighting effect that complements the main lighting installation.
For longer corridors or staircases, multiple Sloane Classic fittings can be positioned at carefully planned intervals to create a consistent architectural lighting scheme. The Polar White finish helps the fittings remain discreet against pale walls during daylight hours.
The warm 3000K output also complements timber flooring, natural stone, decorative wall panels and other interior materials commonly used in residential lighting projects.
Ultra-Slim Recessed Installation
The Sloane Classic range is designed for discreet architectural integration, with an ultra-slim profile that helps minimise the visible appearance of the fitting.
The ALL LED ALSQ032WH/30 Sloane Classic LED Light can be incorporated into suitable recessed wall and plinth installations, subject to the manufacturer’s mounting instructions and available installation dimensions.
Its factory-fitted 1-metre cable provides a convenient connection for routing towards the selected 350mA constant current LED driver. Installers should consider recess depth, cable routes, driver accessibility and the location of electrical connections before completing the installation.
As a 350mA constant current fitting, this product requires a suitable LED driver and must never be connected directly to a 230V mains supply.
Compatible 350mA Constant Current LED Drivers
The ALL LED ALSQ032WH/30 Sloane Classic LED Light requires a suitable 350mA constant current LED driver, which is sold separately.
Driver selection depends on the number of connected fittings, their combined forward voltage, the driver’s permitted operating range and any required dimming functionality. Multiple fittings connected to one compatible constant current driver must be wired in series.
Electrical4Less offers a selection of ALL LED constant current drivers for individual low-level lights and coordinated architectural lighting installations.
- ALL LED ADRCC350/1-11 – 1–11W non-dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/1-4 – 1–4W dimmable 350mA constant current driver.
- ALL LED ADRCC350ANOTD/2-4 – 2–4W dimmable 350mA Nano driver.
- ALL LED ADRCC350TD/4-9 – 4–9W dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/9-18 – 9–18W dimmable 350mA constant current driver.
- ALL LED ADRCC350TD/12-25 – 12–25W dimmable 350mA constant current driver.
- ALL LED ADRCC12D/100-440MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
- ALL LED ADRCC30D/300-900MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
Browse our ALL LED 350mA mains dimmable LED drivers to explore additional driver options for low-level architectural lighting.
Important: A driver’s stated wattage range alone does not guarantee compatibility. Always verify its output voltage range, minimum load, maximum load and approved connection arrangement before installation.
IMPORTANT INSTALLATION INSTRUCTIONS – SERIES WIRING ONLY
WARNING: INCORRECT CONNECTIONS WILL DAMAGE THE LED FITTINGS!
The ALL LED ALSQ032WH/30 Sloane Classic LED Light is a 350mA CONSTANT CURRENT fitting and must be connected to a correctly specified constant current LED driver.
MULTIPLE LED FITTINGS MUST BE CONNECTED IN SERIES – NEVER IN PARALLEL.
- Connect the positive (+) output of the LED driver to the positive (+) connection of the first LED fitting.
- Connect the negative (-) connection of the first fitting to the positive (+) connection of the next fitting.
- Continue connecting additional fittings in series using the same arrangement.
- Connect the negative (-) connection of the final fitting back to the negative (-) output of the driver.
- Never connect these LED fittings directly to a 230V mains supply.
- Never connect or disconnect LED fittings while the driver is energised.
- Complete and inspect all connections before switching on the power supply.
- Observe correct polarity and ensure all electrical connections are secure.
- Check that the driver’s output voltage range and load capacity support the complete series-connected circuit.
- For adjustable constant current drivers, ensure the output is correctly configured to 350mA before energising the circuit.
DO NOT CONNECT THESE FITTINGS IN PARALLEL. INCORRECT WIRING WILL DAMAGE THE LEDs. ALWAYS COMPLETE CONNECTIONS BEFORE SWITCHING ON THE DRIVER.
Always follow the manufacturer’s installation instructions and the wiring diagram supplied with the selected driver. Installation must be carried out by a competent person.
Multiple Sloane Classic Lights and Dimming Control
The ALL LED ALSQ032WH/30 Sloane Classic LED Light can be incorporated into coordinated multi-fitting architectural lighting schemes using a suitably rated 350mA constant current LED driver.
For staircases, corridors and decorative wall installations, several matching fittings can provide consistent warm white illumination with the softer appearance created by the frosted glass diffuser.
When several LED fittings are connected to one driver, their combined forward voltage must fall within the driver’s specified operating range. All connections must be completed securely in series before the circuit is energised.
Where adjustable brightness is required, compatible dimmable drivers can be selected according to the intended lighting control system. ALL LED driver options include mains dimming, DALI and 1–10V control, depending on the selected model.
Energy-Efficient 1W Warm White Low-Level Lighting
With a rated power consumption of just 1W, the ALL LED ALSQ032WH/30 Sloane Classic LED Light provides an energy-efficient solution for decorative architectural lighting and low-level illumination.
Its 3000K warm white output creates a welcoming lighting atmosphere, while the frosted glass diffuser helps soften the light distribution. This combination is particularly useful in residential interiors where comfortable lighting is preferred.
Unlike architectural fittings with clear glass lenses designed to produce pronounced beams, the Sloane Classic delivers a more diffused lighting effect suited to discreet wall and plinth installations.
For larger projects, multiple low-wattage fittings can be used to create a coordinated lighting scheme while keeping individual fitting power consumption low.
Suitable Applications – ALL LED ALSQ032WH/30 Sloane Classic LED Light
The combination of its Polar White finish, warm white output, frosted glass diffuser and IP65 protection makes this recessed fitting suitable for a variety of residential and commercial lighting applications.
- Staircase and step-level wall lighting
- Low-level corridor and hallway illumination
- Decorative recessed wall lighting
- Architectural plinth lighting
- Contemporary residential interiors
- Commercial interior architectural lighting
- Entrance and lobby accent illumination
- Suitable bathroom installations
- Appropriate outdoor architectural lighting locations
- Decorative illumination around architectural wall features
The ALL LED ALSQ032WH/30 Sloane Classic LED Light is particularly useful where gentle, low-glare illumination needs to blend into light-coloured walls and modern interior finishes. Its Polar White design keeps the fitting discreet, while the warm 3000K output creates an attractive decorative lighting effect.
Why Choose the ALL LED Sloane Classic LED Light?
For electricians and lighting designers, the ALL LED ALSQ032WH/30 Sloane Classic LED Light combines energy-efficient 1W operation, a contemporary Polar White finish, frosted glass diffusion and IP65 protection.
Its 350mA constant current design makes it suitable for individual fittings and correctly planned multi-light installations using compatible LED drivers. Dimming can also be incorporated when an appropriate dimmable driver and lighting control system are selected.
