ALL LED ALRD032PC/40 Low Level Light – Oxford Round Polished Chrome 4000K
The ALL LED ALRD032PC/40 Low Level Light is a compact 1W recessed LED fitting designed for decorative staircase lighting, low-level wall illumination and architectural features. Part of the ALL LED Oxford range, this round marker light combines a polished chrome finish, 4000K neutral white output and IP65 protection for residential and commercial installations.
Featuring a frosted glass diffuser and anti-glare design, the Oxford LED light provides soft, evenly distributed illumination without the harsh appearance of an exposed LED source. Its ultra-slim profile allows discreet recessed mounting in suitable walls, staircases and plinths, making it a practical alternative to larger wall-mounted luminaires.
Key Features – ALL LED ALRD032PC/40 Low Level Light
- 1W energy-efficient recessed LED low level light
- 4000K neutral white illumination
- Round Oxford architectural marker light design
- Contemporary polished chrome finish
- IP65 protection against dust and water jets
- Frosted glass diffuser for soft, even light distribution
- Anti-glare design for comfortable illumination
- Ultra-slim profile for discreet installation
- Suitable for recessed staircase, wall and plinth lighting
- Ideal for residential and commercial architectural lighting
- 350mA constant current operation
- Dimmable with a compatible dimmable LED driver
- Supplied with a 1-metre pre-wired cable
- Requires a separate 350mA constant current LED driver
- Multiple fittings must be connected in series using a suitable driver
4000K Neutral White LED Low Level Lighting
The ALL LED ALRD032PC/40 Low Level Light delivers 4000K neutral white illumination, producing a clean, balanced appearance suitable for modern interiors. Unlike warmer 3000K lighting, its neutral white output works particularly well in contemporary staircases, hallways, entrance areas and commercial environments where a crisp decorative lighting effect is preferred.
The frosted glass diffuser helps spread the LED light evenly, creating a softer effect than clear-lens marker lights with sharply defined beams. This makes the Oxford fitting especially suitable for low-level wall lighting where visual comfort and subtle illumination are important.
The 1W LED output allows individual fittings to provide decorative accent lighting while keeping energy consumption low. When several fittings are installed at suitable intervals, they can create a coordinated lighting arrangement along staircases and corridors.
Round Polished Chrome LED Marker Light
The Oxford range features a classic round recessed design with a polished chrome finish, making it suitable for decorative lighting schemes where appearance is just as important as functionality.
The reflective chrome finish complements modern switches, sockets, stainless steel accessories, bathroom fittings and contemporary architectural materials. Its circular profile offers a versatile alternative to square and rectangular low-level lighting fittings.
As a compact round LED marker light, it can be incorporated into suitable wall and plinth surfaces without the visual impact of larger decorative luminaires. The polished chrome surround provides a neat finishing detail while the frosted diffuser softens the light output.
Technical Specifications
| Manufacturer | ALL LED |
|---|---|
| Product Code | ALRD032PC/40 |
| Product Range | Oxford |
| Product Type | Recessed LED Low Level Light / Marker Light |
| Rated Power | 1W |
| Operating Current | 350mA Constant Current |
| Colour Temperature | 4000K Neutral White |
| Finish | Polished Chrome |
| Front Design | Round |
| Diffuser | Frosted Glass |
| Light Distribution | Soft, Even Illumination |
| Glare Control | Anti-Glare |
| IP Rating | IP65 |
| Mounting | Recessed |
| Profile | Ultra-Slim |
| Pre-Wired Cable | 1 Metre |
| Dimmable | With Compatible Dimmable LED Driver |
| LED Driver | Required – Sold Separately |
| Multiple Fitting Wiring | Series Connection with Suitable Constant Current Driver |
LED Staircase Lighting and Low-Level Wall Illumination
The ALL LED ALRD032PC/40 Low Level Light is particularly suitable for staircase lighting projects where discreet illumination is needed along walls and steps. Positioned at appropriate intervals, these recessed LED lights can provide decorative guidance lighting without relying entirely on overhead fixtures.
The round polished chrome front creates an attractive architectural detail, while the anti-glare frosted diffuser helps maintain comfortable illumination when viewed from nearby positions.
For residential staircases, the Oxford low level light can complement ceiling downlights, wall lights and other decorative fittings. It is also useful in corridors and hallways where subtle illumination can enhance the appearance of the surrounding surfaces.
In commercial settings, this type of recessed LED marker light can be incorporated into reception areas, corridors and architectural feature walls. Installation spacing and positioning should be selected according to the desired lighting effect and any applicable illumination requirements.
Ultra-Slim Recessed Design for Modern Interiors
The Oxford LED range is designed for discreet recessed mounting, offering a compact lighting solution for applications where larger fittings would be visually intrusive.
The ALL LED ALRD032PC/40 Low Level Light has an ultra-slim profile that allows it to be integrated into suitable wall and plinth installations, subject to the manufacturer’s specified mounting dimensions.
Its polished chrome finish creates a clean appearance against painted walls, timber panelling, decorative surfaces and contemporary interior materials.
The fitting is supplied with a factory-connected 1-metre cable to assist with connection to a separately installed constant current LED driver. Installers should check the required recess depth, cable routing, driver accessibility and electrical connection arrangement before installation.
Compatible 350mA Constant Current LED Drivers
The ALL LED ALRD032PC/40 Low Level Light operates at 350mA constant current and requires a compatible LED driver, which must be purchased separately.
The correct driver depends on the number of connected fittings, their combined forward voltage, the driver’s permitted operating range and whether dimming functionality is required. Multiple fittings supplied from one compatible constant current driver must be connected in series.
Electrical4Less offers the following ALL LED driver options for consideration. The chosen driver’s electrical specifications must be checked against the intended installation.
- ALL LED ADRCC350/1-11 – 1–11W non-dimmable 350mA constant current LED driver.
- ALL LED ADRCC350TD/1-4 – 1–4W dimmable 350mA constant current LED driver.
- ALL LED ADRCC350ANOTD/2-4 – 2–4W dimmable 350mA Nano LED driver.
- ALL LED ADRCC350TD/4-9 – 4–9W dimmable 350mA constant current LED driver.
- ALL LED ADRCC350TD/9-18 – 9–18W dimmable 350mA constant current LED driver.
- ALL LED ADRCC350TD/12-25 – 12–25W dimmable 350mA constant current LED driver.
- ALL LED ADRCC12D/100-440MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
- ALL LED ADRCC30D/300-900MA – Adjustable constant current driver with DALI and 1–10V dimming. Must be configured to 350mA.
Explore our ALL LED 350mA mains dimmable LED drivers for further driver options and accessories for low-level LED lighting installations.
Important: Matching the driver’s wattage rating alone does not establish compatibility. Always check its minimum and maximum load, output voltage range, current setting and approved connection method before installation.
IMPORTANT INSTALLATION INSTRUCTIONS – SERIES WIRING ONLY
WARNING: INCORRECT CONNECTIONS WILL DAMAGE THE LED FITTINGS!
The ALL LED ALRD032PC/40 Low Level Light is a 350mA CONSTANT CURRENT fitting and must be connected to a suitable constant current LED driver.
MULTIPLE LED FITTINGS MUST BE CONNECTED IN SERIES – NEVER IN PARALLEL.
- Connect the positive (+) output of the driver to the positive (+) connection of the first LED fitting.
- Connect the negative (-) connection of the first fitting to the positive (+) connection of the next fitting.
- Continue the same series arrangement for each additional fitting.
- Connect the negative (-) connection of the final fitting back to the negative (-) output of the driver.
- Never connect the fittings directly to a 230V mains supply.
- Never connect or disconnect fittings while the driver is energised.
- Complete and inspect every connection before applying power.
- Observe the correct polarity and ensure all connections are secure.
- Check that the driver supports the combined forward voltage and power requirements of the LED circuit.
- Ensure adjustable constant current drivers are configured to 350mA before energising the fittings.
DO NOT CONNECT THESE FITTINGS IN PARALLEL. INCORRECT WIRING WILL DAMAGE THE LEDs. ALWAYS COMPLETE ALL CONNECTIONS BEFORE SWITCHING ON THE DRIVER.
Follow the manufacturer’s installation instructions and the wiring diagram supplied with the selected driver. Installation must be carried out by a competent person.
Multiple Oxford LED Marker Lights and Dimming Control
For larger decorative lighting projects, the ALL LED ALRD032PC/40 Low Level Light can be incorporated into a coordinated arrangement of multiple fittings using an appropriately rated 350mA constant current driver.
Several round LED marker lights can be positioned along a staircase, corridor or architectural wall to create a consistent pattern of neutral white illumination. The matching polished chrome finish helps maintain a coordinated appearance throughout the installation.
When multiple fittings are connected to one constant current driver, the combined forward voltage must fall within the manufacturer’s permitted output range. All fittings must be wired correctly in series before the circuit is energised.
Where variable brightness is required, a suitable dimmable driver can be selected according to the intended lighting controls. ALL LED offers driver options for mains dimming, DALI and 1–10V control, subject to the selected model’s specifications.
Energy-Efficient 1W LED Marker Lighting
With a rated power consumption of just 1W, the Oxford round LED low level light provides an energy-efficient solution for decorative stair lighting, recessed wall illumination and architectural features.
The 4000K neutral white output is particularly suitable for modern interiors, while the frosted glass diffuser helps create a smoother light distribution than directional clear-glass fittings.
Using several small recessed marker lights allows lighting designers to introduce decorative illumination at selected positions without relying exclusively on larger general lighting fixtures.
The compact design also provides flexibility for projects where a neat architectural finish is essential and visible wall-mounted luminaires would be undesirable.
Suitable Applications – ALL LED ALRD032PC/40 Low Level Light
The Oxford polished chrome fitting is suitable for a variety of decorative and practical LED lighting applications, including:
- Low level LED staircase lighting
- Recessed step and stairway wall illumination
- Hallway and corridor marker lighting
- Decorative architectural wall lighting
- Recessed plinth lighting
- Modern residential interiors
- Commercial corridors and reception areas
- Suitable bathroom installations
- Appropriately specified outdoor architectural lighting
- Decorative accent lighting around architectural features
The ALL LED ALRD032PC/40 Low Level Light is particularly effective where subtle 4000K illumination needs to complement polished chrome accessories and contemporary interior finishes. Its round design, frosted diffuser and ultra-slim profile make it suitable for lighting schemes where a discreet appearance is important.
Why Choose the Oxford Round LED Low Level Light?
The Oxford range combines simple round styling with practical architectural lighting features. The polished chrome finish offers a contemporary appearance, while the frosted diffuser and anti-glare design provide comfortable neutral white illumination.
For electricians and lighting installers, the ALL LED ALRD032PC/40 Low Level Light offers 350mA constant current operation, a factory-fitted 1-metre cable and compatibility with appropriately specified LED drivers.
Whether used as an individual recessed wall light or within a coordinated staircase lighting arrangement, this 1W LED marker light provides a practical solution for decorative low-level illumination.
Order the ALL LED ALRD032PC/40 Low Level Light from Electrical4Less for professional architectural LED lighting, suitable 350mA drivers and electrical installation accessories.
