EcoPac DALI-2 Constant Voltage LED Driver 200W
The EcoPac DALI2 Push Dimmable LED Driver 200W 24V is a high-power constant voltage LED driver designed for intelligent indoor and outdoor lighting installations. The ELED-200-24DP2 delivers a 24V DC output at up to 8.34A with a maximum rated power of 200W.
Supporting DALI2 and push dimming from 0-100%, this driver provides flexible lighting control for compatible commercial, architectural and intelligent LED lighting systems. The 24V output can also be adjusted from 24V to 26V using NFC regulation.
Key Features
- 24V DC constant voltage LED driver
- 200W rated output power
- 8.34A output current
- DALI2 dimming compatible
- Push dimming function
- 0-100% dimming range
- Constant voltage / PWM output
- NFC output regulation
- 24-26V output adjustment by NFC
- 100-277V AC wide input voltage
- 47-63Hz input frequency
- Built-in active PFC function
- Efficiency up to 91%
- IP66 rated
- Suitable for indoor and outdoor installation
- SELV output
- Class I protection
- Cooling by free air convection
DALI2 and Push Dimming
The EcoPac DALI2 Push Dimmable LED Driver 200W 24V supports both DALI and push dimming control, providing a versatile solution for intelligent LED lighting systems.
Dimming is adjustable from 0-100%, allowing compatible lighting installations to be smoothly controlled through a DALI system or suitable push-dim arrangement. The manufacturer’s wiring diagrams also show integration with DALI power supplies, DALI systems and DALI master control equipment.
NFC Adjustable 24V Output
The ELED-200-24DP2 features NFC regulation, allowing its nominal 24V DC output to be adjusted between 24V and 26V. This provides additional flexibility when commissioning compatible constant voltage LED lighting systems.
The driver uses a constant voltage / PWM output and supplies up to 8.34A at its rated 200W output.
IP66 Indoor and Outdoor Driver
With an IP66-rated enclosure, the ELED-200-24DP2 is designed for both indoor and outdoor installations. This makes it suitable for lighting applications where greater protection against dust and water ingress is required.
Its slim housing measures 278 x 78 x 25.1mm, allowing a high 200W output to be accommodated in a relatively low-profile driver format.
Built-In Electrical Protection
The driver incorporates protection against short circuits, overloading and excessive temperature.
Short-circuit protection operates in constant current mode and automatically recovers once the fault is removed. Overload protection provides constant current limiting at up to 120% and also recovers automatically after the fault condition has been cleared.
Typical Applications
- 24V DALI2 LED lighting systems
- Commercial LED lighting
- Architectural lighting installations
- Intelligent lighting control systems
- 24V constant voltage LED strip lighting
- Indoor LED lighting installations
- Outdoor LED lighting installations
- Push-dim controlled lighting systems
Technical Specifications
- Brand: EcoPac
- Manufacturer: Ecopac (UK) Power Ltd
- Model: ELED-200-24DP2
- Series: ELED-200-DP2
- Driver type: DALI2 and Push dimmable constant voltage LED driver
- Output type: Constant voltage / PWM
- Rated power: 200W
- Output voltage: 24V DC
- NFC adjustable output: 24-26V DC
- Output current: 8.34A
- Voltage tolerance: ±0.2%
- Load regulation: ±2%
- Dimming range: 0-100%
- Dimming control: DALI2 and Push dimming
- Input voltage: 100-277V AC
- Input frequency: 47-63Hz
- Maximum AC current: 2.3A
- Leakage current: Less than 0.50mA
- Inrush current: 59A
- Built-in active PFC: Yes
- Power factor: ≥0.96 at 230V AC full load
- Efficiency: Up to 91%
- Protection class: Class I
- Output classification: SELV
- IP rating: IP66
- Working temperature: -40°C to +70°C
- Working humidity: 20-95% RH, non-condensing
- Dimensions: 278 x 78 x 25.1mm
- Weight: 1.05kg
200W Intelligent LED Lighting Driver
Combining a high 200W output with DALI2 control, push dimming, NFC regulation and IP66 protection, the ELED-200-24DP2 is a versatile solution for professional 24V constant voltage LED installations requiring flexible dimming and intelligent lighting control.
