Description
WCED Type A Bi-Directional Curve B 6A 30mA RCBO – WRB106B-030
Type A Bi-Directional 6A 30mA RCBO
Discover the WRB106B-030 RCBO. A mini, compact size RCBO from Whitecliffe Circuit Protection Company (WCED). These devices offer Type A RCD and overload protection, ideal for PV and EV systems.
Key Features:
- Comprehensive Protection: Detects AC and pulsating DC components.
- Switched Live and Neutral: Isolates faulty circuits.
- Bi-Connect Terminal: Flexible connection options.
- Bi-Directional Use: Suitable for PV and EV systems.
- Ease of Testing: No need to disconnect conductors.
- High Reliability: Maintains service for healthy circuits.
Applications:
- Domestic: Protects household circuits.
- Commercial: Suitable for offices and retail.
- Specialised Systems: Ideal for PV and EV setups.
Specifications:
- Rated Current: 6A
- Rated Voltage: 230V
- Sensitivity: 30mA
- Breaking Capacity: 6kA
- Thermo-Magnetic Release: Curve B
- Protection Degree: IP20
- Operating Temperature: -5 to +40°C
- Terminal Size: Top: 10mm², Bottom: 16mm²
- Mounting: DIN rail EN 60715 (35mm)
Additional Resources
For more details, check out other amperages and WCED RCBO consumer units:
- WCED Type A Bi-Directional Curve B 10A 30mA RCBO – WRB110B-030
- WCED Type A Bi-Directional Curve B 16A 30mA RCBO – WRB116B-030
- WCED Type A Bi-Directional Curve B 20A 30mA RCBO – WRB120B-030
- WCED Type A Bi-Directional Curve B 32A 30mA RCBO – WRB132B-030
- WCED Type A Bi-Directional Curve B 40A 30mA RCBO – WRB140B-030
- WCED RCBO Consumer Unit
Enhance your electrical systems with the WRB106B-030 RCBO from WCED, ensuring comprehensive circuit protection and reliability. Shop now for top-tier electrical safety solutions.
