Description
Compact 15 Way SPD Consumer Unit for 18th Edition Installations
WCED 15 Way SPD Metal Consumer Unit
Upgrade your electrical installation with the WCED 15 Way SPD Metal Consumer Unit. Designed for modern 18th Edition installations, this unit combines reliable electrical distribution with integrated surge protection for domestic and light commercial applications.
The durable metal enclosure features multiple circular cable entry knock-outs across the top, bottom, sides and rear, helping simplify installation and cable routing. Larger rear cable slots provide additional flexibility for internal wiring layouts and easier cable access.
This 18 module consumer unit with 15 usable ways is supplied with a 100A main switch and integrated Type 2 SPD, helping protect electrical systems against transient overvoltage and power surges.
Unlike traditional SPD consumer units, this model supports 1 module double pole RCBOs, removing the need for a separate MCB breaker for the SPD and helping maximise available space within the board.
With compact dimensions of 376mm x 240mm x 112mm, this consumer unit delivers dependable protection and practical installation flexibility for modern domestic and commercial electrical systems.
Key Features – WCED 15 Way SPD Metal Consumer Unit
- Durable metal consumer unit for 18th Edition installations
- Integrated Type 2 surge protection device
- 18 module enclosure with 15 usable ways
- Factory-fitted 100A main switch
- Supports 1 module double pole RCBOs
- No separate MCB breaker required for SPD installation
- 25mm and 32mm knock-outs on top and bottom
- 40mm knock-outs on sides and rear
- Larger rear cable slots for improved wiring access
- Compact design suitable for domestic and small commercial installations
Technical Overview – WCED 15 Way SPD Metal Consumer Unit
- Product code: WME18/SP
- Product type: SPD consumer unit
- Ways: 15 usable ways
- Modules: 18 module enclosure
- Main switch rating: 100A
- Integrated SPD: Type 2
- RCBO compatibility: 1 module double pole RCBOs
- Top and bottom knock-outs: 25mm and 32mm
- Side and rear knock-outs: 40mm
- Dimensions: 376mm (W) x 240mm (H) x 112mm (D)
- Application: Domestic and light commercial electrical distribution
Why Choose This Product?
Choose the WCED WME18/SP when you need a compact SPD consumer unit with integrated Type 2 surge protection, support for 1 module double pole RCBOs and dependable 18th Edition compliant electrical distribution.
