Description
6A Double Pole Single Module RCBO
Note: This RCBO requires a double pole busbar system and will not fit standard consumer units. It is specifically designed for use with the Live Electrical SRN Range Consumer Units.
6A Single Module Type A RCBO for Lighting & PV Solar Circuits
The Live Electrical RNC06B-30N is a compact 6A Double Pole RCBO designed for modern consumer units requiring reliable protection in a space-saving single-module format. Featuring 30mA Type A protection, B Curve tripping characteristics and bi-directional operation, it is suitable for domestic, commercial and PV solar applications.
This RCBO provides reliable protection against overloads, short circuits and earth leakage faults. Its fully bi-directional design makes it suitable for installations where current flow may reverse, including PV solar systems and renewable energy applications.
Designed for use with the Live Electrical SRN double pole busbar system, this RCBO eliminates the need for traditional neutral fly leads when installed within compatible consumer units, creating a cleaner and more organised installation.
Key Features – 6A Double Pole Single Module RCBO
- Type A RCBO – Protects against AC and pulsating DC residual currents
- B Curve Tripping – Suitable for residential and light commercial applications
- 30mA Sensitivity – Rapid disconnection during earth leakage faults
- Single Module Width – Compact space-saving design
- 6A Current Rating – Ideal for lighting circuits and low-demand loads
- Bi-Directional Operation – Suitable for PV solar and renewable energy systems
- Double Pole Switching – Disconnects live and neutral conductors
- Breaking Capacity – 6kA
- Standards Compliance – BS EN 61009-1 certified
Technical Overview – Live Electrical RNC06B-30N
- Product Code: RNC06B-30N
- Current Rating: 6A
- Tripping Curve: B Curve
- Residual Current Sensitivity: 30mA
- Residual Current Type: Type A
- Pole Configuration: Double Pole (2P)
- Module Width: Single Module
- Breaking Capacity: 6kA
- Bi-Directional: Yes
- Standard: BS EN 61009-1
Applications
The Live Electrical RNC06B-30N is ideal for lighting circuits, low-load applications, extensions, outbuildings and modern installations requiring compact Type A RCBO protection. Its bi-directional capability also makes it suitable for PV solar systems and renewable energy installations.
What’s Included
- 1 x Live Electrical RNC06B-30N Double Pole RCBO
Note: Busbar not included.
Why Choose the 6A Double Pole Single Module RCBO?
The RNC06B-30N combines compact sizing, dependable Type A protection and bi-directional functionality within a modern single-module RCBO format. Designed specifically for the Live Electrical SRN range, it helps create cleaner consumer unit installations with improved cable management and faster installation times.
Guarantee & Compliance
All Live Electrical RCBO devices are manufactured to meet current UK standards and are tested for reliable long-term operation. The RNC06B-30N complies fully with BS EN 61009-1 requirements for RCBO protection devices.
Summary of the Live Electrical RNC06B-30N
The Live Electrical RNC06B-30N is a compact 6A Double Pole Type A RCBO designed for use with Live Electrical SRN consumer units. Offering 30mA protection, B Curve characteristics, 6kA breaking capacity and bi-directional operation, it provides reliable protection for modern domestic, commercial and PV solar installations.
