Type A RCBO for Live Electrical TPN Distribution Boards
The Live Electrical 10kA RCBO 20A Curve B Type A 30mA 1P+N provides dual functionality—residual current detection and overcurrent protection in one DIN rail-mounted device. It is designed for use within Live Electrical TPN distribution boards, offering protection against overload, short circuits, and AC or pulsating DC earth leakage currents.
Compliant with BS EN 61009-1 and the 18th Edition Wiring Regulations, this device is ideal for commercial, residential, and light industrial environments.
Electrical Performance and Safety
With a rated current of 20A and Curve B tripping characteristics, this RCBO is suitable for circuits with resistive or low inductive loads, such as socket outlets and lighting. The 30mA residual current sensitivity ensures protection against electric shock and fault leakage.
Its 10kA breaking capacity allows safe disconnection under high fault conditions, ensuring protection across a wide range of electrical applications.
Mounting and Compatibility
The 1P+N configuration enables simultaneous disconnection of both phase and neutral conductors. The device is designed to mount on a standard DIN rail, taking up a single module within Live Electrical TPN three-phase boards.
It supports terminals up to 16mm², making it suitable for typical final circuit cabling requirements.
Key Features
- Designed for Live Electrical TPN distribution boards
- Conforms to BS EN 61009-1
- Rated current: 20A
- 30mA residual current sensitivity (Type A)
- Tripping Curve: B
- Breaking capacity: 10kA
- Configuration: 1P+N
- DIN rail mountable (1 module)
- Terminal capacity: up to 16mm²
- High endurance and minimal nuisance tripping
Technical Specifications – RA120B-030
- SKU: RA120B-030
- Rated Current: 20A
- Voltage: 230V AC
- Tripping Curve: B
- Residual Sensitivity: 30mA, Type A
- Breaking Capacity: 10kA
- Poles: 1P+N
- Mounting: DIN rail, 1 module width
- Terminal Capacity: Up to 16mm²
- Electrical Endurance: 4,000 cycles
- Mechanical Endurance: 10,000 operations
- Operating Temperature: -5°C to +40°C
- Ingress Protection: IP20 (when enclosed)
- Compliance: BS EN 61009-1
Reliable 20A Circuit Protection for Live Electrical Installations
The Live Electrical 10kA RCBO 20A Curve B Type A 30mA 1P+N is a compact, fully compliant solution for protecting final circuits in modern distribution systems. It integrates smoothly into Live Electrical TPN three-phase boards, offering safe, consistent protection where performance and reliability are essential.
