Live Electrical 10kA RCBO 16A Curve C Type A 30mA 1P+N

SKU: RA116C-030
29 In stock
This item cannot be back-ordered
Confirm Availability

16A RCBO with Curve C tripping, 30mA Type A sensitivity, and 10kA fault capacity. 1P+N, single-module DIN rail device for Live Electrical TPN boards. BS EN 61009-1 compliant.

£10.99 + VAT

(incl. VAT £13.19)

— OR —

Description

Type A RCBO with Curve C Tripping for Live Electrical TPN Boards

The Live Electrical 10kA RCBO 16A Curve C Type A 30mA 1P+N is a single-module RCBO designed to provide both residual current protection and overcurrent protection in final circuits. Specifically engineered for use with Live Electrical TPN three-phase distribution boards, it offers reliable performance in circuits with moderate inrush current levels.

Fully compliant with BS EN 61009-1, this RCBO supports safe installations across residential, commercial, and light industrial applications.


Curve C Protection for Mixed-Load Circuits

With a Curve C tripping profile, this device tolerates inrush currents up to 5–10 times its rated current—ideal for circuits powering inductive or capacitive loads such as fans, motors, and lighting systems.

The 30mA residual sensitivity (Type A) ensures timely disconnection in the event of AC or pulsed DC leakage, protecting both people and equipment.


Installation Configuration and Features

This RCBO uses a 1P+N configuration, which enables simultaneous disconnection of phase and neutral conductors. It mounts on a standard DIN rail and occupies a single module space in Live Electrical TPN distribution boards.

The terminals support conductor sizes up to 16mm², ensuring compatibility with standard final circuit wiring.


Key Features

  • Designed for Live Electrical TPN distribution boards
  • Rated current: 16A
  • Tripping curve: C – suitable for inrush-sensitive applications
  • Residual current sensitivity: 30mA (Type A)
  • Breaking capacity: 10kA
  • Pole configuration: 1P+N
  • DIN rail mountable, 1 module
  • Terminal capacity: up to 16mm²
  • Conforms to BS EN 61009-1
  • Durable, compact, and efficient

Technical Specifications – RA116C-030

  • SKU: RA116C-030
  • Rated Current: 16A
  • Voltage: 230V AC, 50Hz
  • Tripping Curve: C
  • Residual Sensitivity: 30mA, Type A
  • Breaking Capacity: 10kA
  • Poles: 1P+N
  • Mounting: DIN rail, single module
  • Terminal Capacity: Up to 16mm²
  • Electrical Endurance: 4,000 operations
  • Mechanical Endurance: 10,000 operations
  • Operating Temperature: -5°C to +40°C
  • Ingress Protection: IP20 (when enclosed)
  • Standards Compliance: BS EN 61009-1

Ideal for Equipment with Moderate Startup Surges

The Live Electrical 10kA RCBO 16A Curve C Type A 30mA 1P+N provides a compliant and robust solution for protecting circuits that experience higher startup current. It integrates seamlessly with Live Electrical TPN boards and supports a wide range of professional installation requirements.

Additional information

Brand

Live Electrical

Curve

C

Fault Current

10kA

Current Rating (A)

16

RCBO / RCD Type

Type A

RCD Trip Current Rating (mA)

30mA

No of Poles

1P
