EcoPac ELED-200P-24T 24V 200W Dimmable LED Driver
The EcoPac ELED-200P-24T 24V 200W Dimmable LED Driver is a premium constant voltage power supply designed for powerful dimmable 24V LED lighting installations. Delivering up to 200W with an 8.3A output, it combines high output capacity with leading and trailing edge Triac dimming compatibility.
The ELED-200P-24T features constant voltage / PWM output, built-in active power factor correction and a robust IP66 aluminium housing. It is suitable for professional LED lighting applications where dependable dimming, high power and enhanced environmental protection are required.
Key Features
- 24V DC constant voltage output
- 200W rated output power
- 8.3A output current
- Leading edge dimmable
- Trailing edge dimmable
- Triac dimming compatible
- Constant voltage / PWM output
- 200-240V AC mains input
- 47-63Hz input frequency
- Built-in active PFC function
- Power factor greater than 0.97 at full load
- Efficiency up to 87%
- IP66 rated
- SELV output
- Full protection aluminium housing
- Cooling by free air convection
Leading and Trailing Edge Triac Dimming
The EcoPac ELED-200P-24T 24V 200W Dimmable LED Driver supports both leading and trailing edge dimming, providing flexibility when used with compatible Triac dimmers and lighting control systems.
This makes the driver suitable for professional mains-dimmable 24V LED lighting installations where smooth control and a high output capacity are required.
Powerful 200W 24V Output
The ELED-200P-24T delivers a regulated 24V DC constant voltage output at up to 8.3A, providing a rated power of 200W.
Its high output capacity makes it particularly suitable for larger LED lighting installations where a single 200W driver can simplify system design compared with using multiple lower-powered units.
Constant Voltage PWM Output
The driver uses constant voltage / PWM output technology to provide controlled power to compatible 24V LED loads.
This design enables dimming while maintaining the required constant voltage output for suitable LED lighting systems.
IP66 Aluminium Housing
The EcoPac ELED-200P-24T features a full protection aluminium housing with an IP66 rating. This provides a high level of protection against dust and water ingress for suitably installed applications.
Cooling is achieved by free air convection, allowing reliable passive operation without an internal fan.
Active PFC and Efficient Operation
Built-in active power factor correction helps improve electrical performance, with the manufacturer specifying a power factor greater than 0.97 at full load.
The driver provides efficiency of up to 87%, making it suitable for high-power professional LED lighting systems.
Integrated Electrical Protection
The ELED-200P-24T incorporates multiple protection functions to support reliable operation.
- Short-circuit protection
- Overload protection
- Over-current protection
- Over-temperature protection
Under specified fault conditions, the output shuts down to protect the driver and connected equipment. The unit can be re-powered once the fault condition has been removed.
Typical Applications
- 24V LED strip lighting
- Architectural LED lighting
- Commercial lighting installations
- Feature lighting
- Display lighting
- Moving signs
- High-power 24V LED installations
- Compatible mains-dimmable LED lighting systems
Technical Specifications
- Brand: EcoPac
- Manufacturer: Ecopac (UK) Power Ltd
- Model: ELED-200P-24T
- Series: ELED-200P-T
- Product type: Triac dimmable constant voltage LED driver
- Output type: Constant voltage / PWM
- Rated power: 200W
- Output voltage: 24V DC
- Output current: 8.3A
- Voltage tolerance: ±0.5V
- Dimming: Leading and trailing edge
- Input voltage: 200-240V AC
- Input frequency: 47-63Hz
- Maximum AC current: 1.4A
- Power factor: PF >0.97 at full load
- Efficiency: Up to 87%
- Leakage current: Less than 0.50mA
- Inrush current: 55A
- IP rating: IP66
- Output classification: SELV
- Working temperature: -40°C to +60°C
- Working humidity: 20-95% RH, non-condensing
- Housing: Aluminium
- Cooling: Free air convection
- Dimensions: 265 x 78 x 47mm
- Weight: 1.45kg
Professional 200W Triac Dimmable LED Driver
Combining a 200W 24V output with leading and trailing edge dimming, active PFC and IP66 protection, the ELED-200P-24T provides a powerful solution for professional constant voltage LED installations requiring reliable mains dimming.
