EcoPac 24V 15W Constant Voltage Low Profile LED Driver
The EcoPac 24V 15W Constant Voltage Low Profile LED Driver is a compact non-dimmable power supply designed for compatible 24V LED lighting installations. The ECP15-24VF-1 provides a regulated 24V DC constant voltage output with a maximum rated power of 15W and output current of approximately 0.62A.
Its slim, lightweight construction makes it particularly suitable for installations where available space is limited, including LED profile lighting and other compatible indoor 24V lighting applications. The IP20 housing incorporates short-circuit and overload protection for dependable operation.
Key Features
- 24V DC constant voltage output
- 15W rated output power
- Maximum output current: approximately 0.62A
- Non-dimmable LED driver
- Low-profile compact design
- 180-264V AC input range
- 50-60Hz input frequency
- IP20 rated
- Short-circuit protection
- Overload protection
- Compact lightweight plastic housing
- Suitable for indoor LED lighting installations
Compact Low Profile Design
The EcoPac 24V 15W Constant Voltage Low Profile LED Driver measures just 103 x 35.5 x 16mm, providing a highly compact solution for LED lighting installations where driver space is restricted.
The lightweight plastic enclosure is designed for straightforward installation while keeping the overall footprint to a minimum.
24V Constant Voltage Output
The ECP15-24VF-1 is designed specifically for compatible 24V constant voltage LED loads. It provides up to 15W of output power with a maximum output current of approximately 0.62A.
As a constant voltage driver, it is suitable for compatible 24V LED products requiring a stable DC supply rather than a constant current power source.
Non-Dimmable LED Driver
This model is a standard non-dimmable LED driver. It is intended for applications where simple on/off operation is required rather than mains, DALI or other dimming control.
Built-In Protection
The ECP15-24VF-1 incorporates protection against short circuits and overload conditions, helping protect the driver during abnormal operating conditions.
Typical Applications
- 24V LED strip lighting
- LED profile lighting
- Display lighting
- Cabinet and furniture lighting
- Lightboxes
- Indoor architectural lighting
- Compact 24V LED installations
Technical Specifications
- Brand: EcoPac
- Manufacturer: Ecopac Power
- Model: ECP15-24VF-1
- Series: ECP15-VF-1
- Product type: Constant voltage LED driver
- Dimmable: No
- Rated power: 15W
- Output voltage: 24V DC
- Output current: 0-0.62A
- Input voltage: 180-264V AC
- Input frequency: 50-60Hz
- IP rating: IP20
- Housing: Plastic
- Working temperature: -20°C to +45°C
- Maximum case temperature: +85°C
- Dimensions: 103 x 35.5 x 16mm
- Safety standards: EN61347-1 and EN61347-2-13
15W 24V LED Power Supply
With its compact dimensions, 24V constant voltage output and low-profile housing, the ECP15-24VF-1 is a practical power supply for smaller indoor LED lighting projects requiring up to 15W of non-dimmable power.
