6A Curve B 30mA A Type RCBO – Switched Line & Neutral, 6kA, Space Saver
Targeted Protection for Low-Load Circuits – Niglon RCBO1-6/30SSAX 6A RCBO
Niglon RCBO1-6/30SSAX
The Niglon RCBO1-6/30SSAX is a compact, high-performance RCBO designed to provide both overcurrent and earth fault protection in one single device. Rated at 6 amps with a Curve B tripping profile, it’s ideally suited for resistive loads such as lighting circuits, heating controls, and small domestic appliances.
With a breaking capacity of 6kA, this space-saving device is built to perform under fault conditions, disconnecting both line and neutral for added safety. The unit features Type A RCD sensitivity, meaning it can detect both AC and pulsating DC residual currents, offering enhanced protection in line with the latest 18th Edition wiring regulations.
Whether you’re upgrading a consumer unit or working on a new installation, this RCBO is a perfect fit for applications where space, safety, and compliance matter.
Key Features of the Niglon RCBO1-6/30SSAX
- Rated Current: 6A – Ideal for lighting circuits and other low-load installations
- Tripping Curve: Curve B – Trips between 3 to 5 times the rated current, ideal for resistive loads
- Residual Current: 30mA – Provides personal protection against electric shock
- RCD Type: A – Detects AC and pulsating DC residual currents
- Switched Line & Neutral – Enhances isolation and safety during maintenance
- Breaking Capacity: 6kA – Suitable for most domestic and light commercial installations
- Space Saver Design: 18mm Width – Maximises space within consumer units
- Compliance:
- BS EN 61009-1
- BS7671:2018 (18th Edition Wiring Regulations)
Applications
- Lighting Circuits – Especially in domestic environments where loads are low and sensitivity is essential
- Control Panels – Offering enhanced protection for small-scale systems
- Residential Installations – Ideal for protecting circuits in flats, houses, or HMOs
- Board Upgrades – Excellent choice when replacing older protective devices with 18th Edition-compliant solutions
Why Choose the Niglon RCBO1-6/30SSAX?
This RCBO is not only compact and easy to install, but also meets the latest safety requirements for low-load circuits. The Curve B profile makes it perfect for sensitive applications, while the Type A detection ensures protection against modern residual current faults – including those produced by electronic devices.
With its slim 18mm width and switched line and neutral functionality, it’s an exceptional option for any space-conscious installation that requires reliable and regulation-ready protection.
Summary
The Niglon RCBO1-6/30SSAX is a 6A, Curve B, 30mA A Type RCBO designed for lighting and low-current circuits. Featuring switched line and neutral disconnection, Type A RCD protection, and a space-saving 18mm design. This RCBO ensures full compliance with BS EN 61009-1 and 18th Edition standards. Ideal for modern residential and small commercial applications.
