40A Curve B 30mA Bi-Directional A Type RCBO – Compact RCBO, Switched Line & Neutral, 6kA
Heavy-Duty Circuit Protection for Solar and Power Loads – Niglon RCBO1-40/30SAX2 40A RCBO
Niglon RCBO1-40/30SAX2
The Niglon RCBO1-40/30SAX2 40A RCBO offers robust, compact protection for high-load circuits such as electric showers, cookers, and heating systems. It features a Curve B tripping profile, 30mA Type A RCD, and bi-directional current detection—making it ideal for solar-ready installations.
In PV systems, exported energy may cause reverse current flow through protective devices. Many RCBOs are not designed for this. However, this model continues to monitor and disconnect safely regardless of direction, offering true PV compliance.
Its compact 18mm footprint fits neatly into modern boards. With switched line and neutral disconnection, it allows safe testing and maintenance—ensuring both safety and convenience.
Key Features of the Niglon RCBO1-40/30SAX2 40A RCBO
- 40A Current Rating – Ideal for electric showers, cookers, and high-load appliances
- Curve B Tripping – Responds at 3–5 times rated current
- 30mA Type A RCD – Detects AC and pulsating DC leakage
- Bi-Directional Fault Detection – Required for reverse-flow circuits in PV systems
- Switched Line & Neutral – Ensures complete isolation and safer servicing
- Breaking Capacity: 6kA – Complies with domestic board standards
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² line in, 10mm² line/neutral out
- Width: 18mm – Compact RCBO for consumer units with limited space
- Standards: BS EN 61009-1, BS7671:2018 (18th Edition)
Applications
- Electric shower and cooker circuits
- High-power kitchen and utility loads
- Solar PV installations with reverse current flow
- Upgrades to 18th Edition consumer boards
Why Choose the Niglon RCBO1-40/30SAX2 40A RCBO?
The Niglon RCBO1-40/30SAX2 40A RCBO is built for demanding applications. It ensures full compliance and safety, even when energy flows in reverse. With bi-directional Type A protection, Curve B tripping, and a compact profile, it’s a future-ready choice for smart electrical installations.
Summary
The Niglon RCBO1-40/30SAX2 40A RCBO is a bi-directional, Type A, 30mA RCBO for high-load circuits and solar-ready boards. It features Curve B protection, switched line and neutral, and a compact 18mm body.
