20A Curve B 30mA A Type RCBO – Mini RCBO, Switched Line & Neutral, 6kA
Dependable Protection for General Load Circuits – Niglon RCBO1-20/30SSAX 20A RCBO
Niglon RCBO1-20/30SSAX
The Niglon RCBO1-20/30SSAX 20A RCBO offers compact, regulation-compliant protection for a range of general power circuits. Combining overcurrent and 30mA residual current protection in one 18mm-wide module, it saves valuable space in modern consumer units.
Designed with a Curve B tripping profile, this RCBO is well suited for sockets, lighting banks, immersion heaters, and other resistive or mixed-load applications. It features a Type A RCD, capable of detecting both AC and pulsating DC leakage faults, making it reliable for circuits with electronic devices or appliances.
Moreover, its switched line and neutral isolation enhances safety during servicing or when faults occur—offering complete disconnection and peace of mind.
Key Features of the Niglon RCBO1-20/30SSAX 20A RCBO
- Rated Current: 20A – Ideal for sockets, heaters, and small fixed loads
- Curve B Tripping – Trips between 3–5x rated current for resistive/mixed loads
- 30mA Type A RCD – Detects AC and pulsating DC earth leakage
- Switched Line & Neutral – Full circuit disconnection during fault conditions
- 6kA Breaking Capacity – Compliant with domestic and light commercial standards
- Compact Mini RCBO – Space-saving 18mm width
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² (line in), 10mm² (line/neutral out)
- Standards: BS EN 61009-1, BS7671:2018 (18th Edition)
Applications
- Socket outlets on 20A radial circuits
- Small storage heaters or immersion heaters
- Garden and outbuilding power
- General-purpose domestic and commercial circuits
Why Choose the Niglon RCBO1-20/30SSAX
The Niglon RCBO1-20/30SSAX 20A RCBO is a compact, reliable solution for mid-range power circuits. It provides both residual and overload protection, with Type A RCD sensitivity and switched line and neutral isolation. It’s ideal for boards where space, safety, and compliance all matter.
Summary
The Niglon RCBO1-20/30SSAX RCBO is a Curve B, Type A mini RCBO that protects against overcurrent and 30mA earth leakage. It features switched line and neutral disconnection, a 6kA rating, and a compact 18mm width—ideal for sockets and mixed-load circuits.
