Description
10A Curve B 30mA Bi-Directional A Type RCBO – Compact RCBO, Switched Line & Neutral, 6kA
Safe Power Distribution for Domestic and Solar PV – Niglon RCBO1-10/30SAX2 10A RCBO
Niglon RCBO1-10/30SAX2
The Niglon RCBO1-10/30SAX2 10A RCBO is a compact, bi-directional protective device designed for lighting and small power circuits. Because it detects earth leakage and overcurrent faults in both current directions, it is ideal for solar PV systems where reverse energy flow is common.
Many standard RCBOs do not operate correctly when current flows in reverse, such as from a solar inverter back into the board. However, this bi-directional RCBO continues to protect your circuit regardless of direction—making it perfect for PV-ready consumer units or energy-efficient upgrades.
This Curve B, Type A RCBO provides overload, short circuit, and 30mA residual current protection. It includes switched line and neutral, offering full disconnection and safer maintenance. With an 18mm footprint, it easily fits modern, space-limited boards.
Key Features of the Niglon RCBO1-10/30SAX2 10A RCBO
- Rated Current: 10A – Great for lighting and socket outlets
- Curve B Tripping – Trips at 3–5x rated current for resistive or mixed loads
- Bi-Directional Design – Essential for PV solar installations with reverse current
- 30mA Type A RCD – Detects AC and pulsating DC earth leakage
- Switched Line & Neutral – Improves safety and simplifies fault isolation
- Breaking Capacity: 6kA – Domestic and light commercial board compliant
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² line in, 10mm² line/neutral out
- Width: 18mm – Compact RCBO ideal for modern units
- Standards: BS EN 61009-1, BS7671:2018 (18th Edition)
Applications
- General lighting and socket circuits
- Solar PV installations needing bi-directional protection
- Home offices, sheds, or garden buildings
- Consumer unit upgrades to meet 18th Edition
Why Choose the Niglon RCBO1-10/30SAX2 10A RCBO?
The Niglon RCBO1-10/30SAX2 10A RCBO offers space-saving safety with full 18th Edition compliance. Its bi-directional capability makes it perfect for circuits with potential reverse flow, especially in solar energy setups. You get all-in-one fault detection and isolation—backed by Niglon’s trusted reliability.
Summary
The Niglon RCBO1-10/30SAX2 10A RCBO is a compact, Curve B, Type A device with 30mA RCD and overload protection. Its bi-directional operation makes it ideal for solar PV circuits and 18th Edition boards.
