Live Electrical Double Pole Type A RCBO – Curve C – 20A

SKU: RA220C-030

In stock (22) More Available within 1-2 Working Days*

Type A

Breaking capacity(Icn): 10kA

Electrical endurance: 4,000 cycles

Mechanical endurance: 10,000 cycles

Complies with BS EN 61009-1

Dispatch Info
Cut off time for Dispatch Delivery: Mon-Thu 2pm*
Cut off time for Saturday Delivery : Friday 2pm*
All orders placed on Sat/Sun will be dispatched on Monday.
Technical Support
Live Electrical Technical Support 0161 870 2592

£19.99 + VAT

(incl. VAT £23.99)

Description

Live Electrical Double Pole Type A RCBO – Curve C – 20A

Live Electrical Double Pole Type A RCBO

LIVE brand Type A RCBOs are designed specifically for individual EV chargers, where the model and make of the vehicle being charged is unknown.

They can detect & respond as for type AC, plus pulsating DC components.

◆ Rated current(In): 6A,10A,16A,20A,25A,32A,40A

◆ Rated voltage(Un): 230V AC

◆ Breaking capacity(Icn): 10kA

◆ Rated residual current: 30mA

◆ Tripping characteristics: B,C

◆ Electrical endurance: 4,000 cycles

◆ Mechanical endurance: 10,000 cycles

◆ Complies with BS EN 61009-1



Additional information

Amperage

6, 20

Curve

C

Fault Current

6kA
