10A Type A Mini Bi-Directional RCBO – 100mA B Curve
The Live Electrical AMR110B-100 RCBO 100mA offers robust protection for 10A circuits where standard 30mA RCDs cause false tripping. Its 100mA Type A sensitivity supports stability while ensuring safe disconnection during faults.
Live Electrical AMR110B-100 – 100mA Bi-Directional Type A RCBO
Electricians use this RCBO on selected PV and solar installations, where higher leakage currents are normal and 30mA protection isn’t necessary. The compact single-module design fits modern consumer units, while the Bi-Directional layout adds flexibility during installation.
This model includes overload, short-circuit, and residual current protection in one unit. Its B Curve tripping profile ensures fast response under fault conditions, and the 6kA breaking capacity handles high prospective fault currents. It fully complies with BS EN 61009-1.
Electricians must avoid using this device on any circuit that requires 30mA RCD protection. Always assess the installation and confirm compliance with BS 7671 before fitting.
Key Features of the Live Electrical AMR110B-100 100mA RCBO
- Rated Current: 10A
- Tripping Curve: Type B
- RCD Type: Type A
- Tripping Sensitivity: 100mA – ideal for specialist applications
- Voltage: 230V AC
- Breaking Capacity: 6kA
- Compact single module width
- Conforms to BS EN 61009-1
- Terminal capacity: IN 16mm² / OUT 10mm²
About Live Electrical
Live Electrical builds dependable circuit protection for real-world use. Their RCBOs meet UK standards, install quickly, and perform consistently. Electricians across the country trust the brand for compact, regulation-ready components.
Why Buy From Electrical4Less?
Electrical4Less brings you fast delivery, excellent service, and a wide selection of regulation-compliant products at competitive prices. We’re trusted by professionals across the UK.
Summary of the Live Electrical AMR110B-100 100mA RCBO
Install the AMR110B-100 on 10A circuits that require 100mA Type A protection. It suits selected PV and solar setups, especially where 30mA sensitivity causes issues. Its Bi-Directional format and slim design streamline installation. Use this device only where 30mA protection is not required. A qualified electrician must confirm its suitability and install it according to BS 7671.
