Description
Live 30mA 40A RCBO 10kA Curve C Type AC
It can be used in single and three phase installations distribution boards – 10kA
Descriptions & Features
- Provides complementary protection against direct contact by human body
- Effectively protects electric equipment against insulating failure
- Handle can be locked with pad-lock to prevent unwanted operation for safety
- Technical Data
- Rated Current(In): 6-40Amp
- Rated Voltage(Un): 230V AC
- Breaking Capacity(Icn) 10kA
- Rated residual current: 30mA
- Tripping characteristics: B
- Electrical endurance: 4000 cycles
- Mechanical endurance: 10000 cycles
RCBO (Residual Current Circuit Breakers with Overcurrent Protection) devices are a combination of an RCD (Residual Current Device) and MCB (Miniature Circuit Breaker) in one.
An RCD detects Earth Leakage, i.e. current flowing where it shouldn’t, switching the circuit off where there is an Earth fault current. The RCD element of the RCBO is there to protect people.
Live Electrical believes in high product quality while offering competitive prices. We supply a wide range of products and swift, reliable delivery
All Live products are certified to UK standards and meet the current wiring regulations
