FuseBox RTB06B25BD 25A Type B Bidirectional RCBO
25A 2 Pole Type B RCBO with 30mA Protection
The FuseBox RTB06B25BD 25A Type B Bidirectional RCBO is a 25A two-pole protective device from FuseBox’s Type B bidirectional RCBO range. It provides 30mA earth-leakage protection alongside overcurrent and short-circuit protection, with a 6kA prospective fault current rating.
FuseBox developed this range for installations involving modern electronic equipment, with Type B residual-current detection covering smooth DC as well as pulsed DC and AC fault currents. Its two-pole construction combines residual-current, overcurrent and short-circuit protection in one bidirectional protective device.
Key Features
- 25A current rating
- Type B residual-current protection
- Bidirectional operation
- 2-pole design
- 30mA earth-leakage protection
- Overcurrent protection
- Short-circuit protection
- Detects smooth DC, pulsed DC and AC residual fault currents
- 6kA PFC
- Suitable for domestic and industrial applications
- Compatible with FuseBox single-phase and TPN ranges
- 5-year FuseBox guarantee
Type B Protection for Modern Electrical Loads
The FuseBox RTB06B25BD 25A Type B Bidirectional RCBO is intended for circuits where the installation design calls for Type B residual-current detection. Because the device detects smooth DC residual currents as well as pulsed DC and AC, it addresses a wider fault-current spectrum than Type A or Type AC devices. The final RCBO type and rating must always be selected to suit the connected equipment and installation design.
Compare the complete FuseBox Type B Bidirectional RCBO range or browse all FuseBox RCBOs available from Electrical4Less. For compatible three-phase distribution equipment, see our FuseBox three phase TPN distribution boards.
Bidirectional 2 Pole Circuit Protection
With its 25A rating, 30mA residual-current sensitivity and 6kA PFC, the FuseBox RTB06B25BD 25A Type B Bidirectional RCBO gives installers a dedicated Type B option within the FuseBox circuit-protection range. Its bidirectional operation supports applications where power flow is not limited to a single direction.
