EcoPac Triac Dimmable LED Driver 60W 24V
The EcoPac Triac Dimmable LED Driver 60W 24V is a premium constant voltage LED power supply designed for compatible dimmable LED lighting systems. The ELED-60P-24T provides a 24V DC output at up to 2.5A, delivering a rated output power of 60W.
Supporting both leading edge and trailing edge dimming, this driver can be used with compatible TRIAC dimmers and lighting control systems. It also features constant voltage / PWM output, built-in active power factor correction and an IP20 protective housing.
Key Features – EcoPac Triac Dimmable LED Driver 60W 24V
- 24V DC constant voltage output
- 60W rated output power
- 2.5A output current
- Leading edge dimmable
- Trailing edge dimmable
- TRIAC dimming compatible
- Constant voltage / PWM output
- 200-240V AC input
- 47-63Hz input frequency
- Built-in active PFC function
- Power factor greater than 0.98 at full load
- Typical full-load efficiency up to 85%
- IP20 rated
- SELV output
- Full protection plastic housing
- Cooling by free air convection
Leading and Trailing Edge Dimming
The EcoPac Triac Dimmable LED Driver 60W 24V supports both leading and trailing edge dimming, providing flexibility when used with compatible TRIAC dimmers.
The manufacturer also shows the ELED-60P-T series connected through a TRIAC dimmer or compatible home automation lighting system, making the driver suitable for controlled 24V LED lighting installations.
Constant Voltage PWM Output
The ELED-60P-24T provides a constant voltage / PWM output at 24V DC. With a maximum output current of 2.5A and rated power of 60W, it is designed for compatible 24V LED lighting and moving sign applications.
Built-In Electrical Protection
The driver incorporates multiple protection functions for dependable operation, including protection against short circuits, overloading, over current and excessive temperature.
Under specified fault conditions, the output is designed to shut down. The driver can then be re-powered once the fault condition has been removed.
Active PFC and Efficient Performance
Built-in active power factor correction provides a power factor greater than 0.98 at full load. Typical full-load efficiency is rated at up to 85%, helping the ELED-60P-24T provide efficient power conversion for compatible LED lighting systems.
Applications
- 24V dimmable LED lighting
- Compatible 24V LED strip lighting
- LED lighting systems
- Moving signs
- Lighting controlled by compatible TRIAC dimmers
- Compatible home automation lighting systems
Technical Specifications
- Brand: EcoPac
- Manufacturer: Ecopac (UK) Power Ltd
- Model: ELED-60P-24T
- Series: ELED-60P-T
- Driver type: TRIAC dimmable constant voltage LED driver
- Output type: Constant voltage / PWM
- Output voltage: 24V DC
- Output current: 2.5A
- Rated power: 60W
- Dimming: Leading edge and trailing edge
- Input voltage: 200-240V AC
- Input frequency: 47-63Hz
- Maximum AC current: 0.38A
- Power factor: PF >0.98 at full load
- Typical full-load efficiency: 85%
- Leakage current: Less than 0.50mA
- Inrush current: 50A
- IP rating: IP20
- Output classification: SELV
- Working temperature: -40°C to +70°C
- Working humidity: 20-90% RH, non-condensing
- Dimensions: 178 x 61 x 24mm
- Weight: 0.35kg
Compact IP20 Housing
The ELED-60P-24T measures 178 x 61 x 24mm and weighs 0.35kg. Its full-protection plastic housing is cooled by free air convection, providing a compact solution for indoor installations requiring a 60W 24V TRIAC dimmable constant voltage LED driver.
