Description
40A Curve C Type B Bi-Directional RCBO
Live Electrical RKB140C-030
This 40A Curve C Type B Bi-Directional RCBO is a compact, high-performance single-module protective device designed for modern residential and light-commercial installations. With Type B sensitivity, it is suitable for circuits that include DC components such as EV chargers, solar inverters, heat pumps and smart control systems.
Providing a 6kA breaking capacity, this RCBO delivers reliable short-circuit and overload protection. As a double-pole device, it isolates both live and neutral conductors for enhanced safety. The bi-directional feed allows supply from either the top or bottom, offering maximum flexibility during installation or upgrades.
This unit requires a double-pole busbar for correct installation. Use the compatible model: Live Electrical Double Pole 63A Copper Busbar 1m 10mm² 108 Pin – SKU: DPN63A.
Technical Details – 40A Curve C Type B Bi-Directional RCBO
- Rating: 40A
- Tripping characteristic: Curve C
- Type: Type B (DC-influenced circuits)
- Configuration: Single Module 1P+N
- Isolation: Double Pole (L + N)
- Breaking capacity: 6kA
- Feed orientation: Bi-Directional (top or bottom)
- Brand: Live Electrical
- Required busbar: DPN63A
- Suitable for: domestic and light-commercial distribution boards
Typical Applications – 40A Curve C Type B Bi-Directional RCBO
- EV chargers and home charging points
- Heat pumps and HVAC circuits
- Solar PV and hybrid inverter systems
- Smart home and automation circuits
- LED driver and electronic load circuits
- Installations requiring Type B protection
Related & Compatible Products
Explore the full range of Type B RCBOs:
Type B RCBO Product Tag
For installation, use the matching double-pole busbar:
Live Electrical Double Pole 63A Copper Busbar 1m 10mm² 108 Pin – DPN63A
