3 Core 16mm H6943X XLPE SWA PVC Steel Wire Armoured Cable – 50 Metres

SKU: H6943XL716/50
Delivery usually within 1-3 working days*
Confirm Availability

Conductor: Plain Annealed Copper, offering excellent conductivity and flexibility

Insulation: XLPE (Cross-Linked Polyethylene), providing resistance to heat and chemicals

Inner Bedding: PVC, for added insulation and safety

Armour: Galvanised Steel Wire, which protects against mechanical stress

Outer Sheath: PVC, ensuring UV and weather resistance

This 50-metre industrial armoured cable from Doncaster Cables combines flexibility and durability, making it suitable for demanding power setups. Built to BS 5467 standards, it provides dependable performance in challenging environments.

£432.90 + VAT

(incl. VAT £519.48)

Description

3 Core 16mm PVC SWA XLPE Cable – 50 Meters

Doncaster Cables H6943XL716/50

The Doncaster Cables H6943XL716/50 3 Core 16mm Armoured Cable provides durable and efficient power distribution, suited for industrial applications requiring resilience and dependability. Available in a 50-metre length, this cable adheres to BS 5467 standards, delivering robust protection for installations in demanding environments.


Product Overview

This 50-metre armoured cable features a stranded copper conductor, high-temperature-resistant XLPE insulation, and a strong PVC sheath. Its adaptable design makes it suitable for various installation types, including in air, on trays, ladders, embedded in concrete, or buried directly in ducting, ensuring flexibility for a range of industrial needs.


Key Features

  • Length: 50 metres, ideal for medium-scale industrial projects
  • Voltage Rating: 600/1000V, providing safe, reliable power distribution
  • Conductor: Plain Annealed Copper, Class 2 Stranded, compliant with BS EN 60228
  • Insulation: Thermosetting XLPE, Type GP8, adhering to BS 7655-1.3 standards
  • Sheath: Tough PVC Type 9, in line with BS 7655-4.2 standards
  • Temperature Range: Operates from -15°C to 90°C, making it suitable for diverse conditions
  • Minimum Bending Radius: 8 x diameter (∅), allowing for easier handling during installation
  • Core Colours: Brown, Black, Grey for straightforward identification
  • Sheath Colour: Black, ensuring compliance and visibility in installation areas
  • Current Ratings: Refer to BS7671 IET Wiring Regulations Table 4E4A for current capacity

Designed for BS 5467 Standards Compliance

The H6943XL716/50 cable from Doncaster Cables fully complies with BS 5467 standards, guaranteeing performance and reliability in industrial environments. With a stranded copper conductor, XLPE insulation, and steel wire armour, it’s engineered to provide both safety and durability for power distribution setups.


Conductor and Insulation

Built with a Class 2 stranded copper conductor (BS EN 60228), this cable ensures stable conductivity for high-power applications. Its XLPE insulation (Type GP8) tolerates temperatures up to 90°C, offering consistent performance across diverse industrial conditions.


Protective Sheathing and Armouring

Equipped with a robust PVC sheath (Type 9, BS 7655-4.2) and galvanized steel wire armour, this cable provides enhanced protection. Suitable for installations on trays, ladders, in concrete, or buried in ducting, it’s designed to withstand demanding conditions and offer a secure setup for high-risk areas.


Benefits of Doncaster Cables H6943XL716/50 Armoured Cable

  • Great for Industrial Power Needs: Built to handle medium-sized industrial and construction applications
  • Flexible Installation Choices: Suitable for air, tray, ladder, concrete, or ducted installations
  • Enhanced Protection: XLPE insulation and steel armour shield the cable from heat, wear, and impact

The Doncaster Cables H6943XL716/50 3 Core 16mm PVC SWA XLPE Armoured Cable offers a versatile, durable solution for industrial power distribution. Its 50-metre length, strong build, and compliance with UK standards make it ideal for installations requiring a balance of flexibility and resilience.

Downloads

View Product Data Sheet Data Sheet

Additional information

Brand

Doncaster Cables

Number of Cores

3 Core

Insulation

XLPE – Thermosetting

Sheath

PVC

Product

SWA Steel Wire Armoured Cable

Size

16mm

Length

50m
