20A Curve C Type B Bi-Directional RCBO
Live Electrical RKB120C-030
This 20A Curve C Type B Bi-Directional RCBO is engineered for circuits where sensitive electronic loads or DC leakage may be present, including smart home systems, lighting groups, control circuits and modern power supplies. Its compact single-module format is ideal for consumer units with limited space.
The 6kA breaking capacity ensures dependable protection against overloads and short circuits, while the double-pole design isolates both live and neutral conductors for improved safety during fault conditions. The bi-directional feed capability allows installers to connect supply from either top or bottom, offering flexibility during new installations or upgrades.
This RCBO requires a compatible double-pole busbar. Use the matching model: Live Electrical Double Pole 63A Copper Busbar 1m 10mm² 108 Pin – SKU: DPN63A.
Technical Details – 20A Curve C Type B Bi-Directional RCBO
- Rating: 20A
- Tripping characteristic: Curve C
- Type: Type B (suitable for DC-influenced circuits)
- Configuration: Single Module 1P+N
- Isolation: Double Pole (L + N)
- Breaking capacity: 6kA
- Feed direction: Bi-Directional (top or bottom)
- Brand: Live Electrical
- Required busbar: DPN63A
- Applications: lighting, controls, smart home and electronic loads
Typical Applications – 20A Curve C Type B Bi-Directional RCBO
- Lighting circuits and LED driver systems
- Automation and smart home controls
- Home technology equipment with DC leakage
- Small EV accessories and electronic loads
- Solar control and monitoring circuits
- Boards requiring Type B protection in lower current ranges
Related & Compatible Products
Explore the full range of Type B RCBOs:
Type B RCBO Product Tag
For installation, use the matching double-pole busbar:
Live Electrical Double Pole 63A Copper Busbar 1m 10mm² 108 Pin – DPN63A
