WCED Miniature Circuit Breaker 6kA Curve B – 16A

SKU: WMC116B

In stock (20) More available within 1-3 working days*

Dispatch Info

Cut off time for Dispatch Delivery: Mon-Thu 2pm*
Cut off time for Saturday Delivery : Friday 2pm*
All orders placed on Sat/Sun will be dispatched on Monday.

Technical Support

WCED Technical Support 0161 723 1451

£1.53 + VAT

(incl. VAT £1.84)

Description

WCED Miniature Circuit Breaker 6kA Curve B – 16A

Available in single pole or triple pole

Rated voltage Ue(AC): 230/400V

Rated frequency 50/60Hz

Insulation voltage Ui: 500V

Rated breaking capacity (A): 6/10Ka

Rated impulse withstand voltage (1.2/50) Uimp (V): 4000

Dielectric test voltage at ind. Frq for 1 min (KV): 2

Thermo-magnetic release characteristic: B,C,D

Electrical life 8000

Mechanical life: 20,000

Contact position degrees: IP20

Reference temperature for setting of thermal element (C): 30

Ambient temperature (with daily average <35 C: 5 – +40)

Storage temperature (C): -25 – +70

Additional information

Brand	WCED
Curve	B
No of Poles	1
Fault Current	6kA
Amperage	16
