WCED WEV263B-030 Bi-Directional B Type RCCB for EV & Advanced Electrical Systems
The WCED WEV263B-030 is a high-performance 2 Pole 63A 30mA Type B RCD designed for advanced electrical installations requiring protection against AC and DC residual fault currents. Engineered for modern applications including EV charging, photovoltaic systems, UPS equipment and inverter-driven loads, this bi-directional RCCB delivers reliable fault protection in demanding environments.
Unlike standard Type AC or Type A devices, the WEV263B-030 detects AC, pulsating DC and smooth DC residual currents, including high-frequency leakage currents up to 1kHz. Its 30mA trip sensitivity provides additional protection against electric shock and automatic disconnection under fault conditions.
Key Features – 2 Pole 63A 30mA Type B RCD
- Bi-Directional 2 Pole 63A B Type RCCB
- 30mA residual current sensitivity
- Detects AC, pulsating DC and smooth DC fault currents
- Suitable for EV charging and solar PV systems
- High-frequency residual current detection up to 1kHz
- 10kA short-circuit breaking capacity
- Impulse withstand voltage: 4.5kV
- Mechanical endurance: 4000 operations
- Electrical endurance: 2000 operations
- IP20 terminal protection
Technical Specifications – 2 Pole 63A 30mA Type B RCD
- Brand: WCED
- Part Code: WEV263B-030
- Device Type: B Type RCCB
- Poles: 2 Pole
- Rated Current: 63A
- Trip Sensitivity: 30mA
- Rated Voltage: 230/240V AC
- Insulated Voltage: 500V
- Impulse Withstand Voltage: 4.5kV
- Breaking Capacity: 10kA
- Residual Making & Breaking Capacity: 1000A
- Protection Degree: IP40 body / IP20 terminals
- Terminal Capacity: 35mm²
- Ambient Temperature: -25°C to +40°C
- Standards: IEC/EN 61008-1 & IEC/EN 62423
Applications
The WCED WEV263B-030 Bi-Directional B Type RCCB is suitable for installations where smooth DC leakage currents may be present. Typical applications include EV charging points, photovoltaic systems, battery storage installations, UPS systems, frequency converters and advanced commercial electrical systems.
Why Choose WCED Type B RCCBs?
WCED Type B residual current devices are specifically designed for modern electrical systems containing electronic equipment and inverter technology. Their advanced sensing capability ensures reliable protection against complex residual current waveforms that conventional RCDs may not detect correctly.
