Switchtec DOL22-11-240VAC 22A DOL Starter
The Switchtec DOL22-11-240VAC 22A DOL Starter is an enclosed direct-on-line motor starter designed for straightforward motor switching and overload protection. This model uses a 240V control coil and is rated at 22A, with a 11kW motor rating and 40A AC1 duty.
Product Overview
Supplied with a thermal overload relay covering 16-22A, this SCL DOL starter combines the contactor, overload protection and enclosure in one practical assembly. The enclosure uses a mild steel base finished in RAL7012 with an ABS plastic cover in RAL7035 and provides IP44 ingress protection.
Key Features
- 22A direct online starter with 240V coil voltage
- 11kW motor rating
- 40A AC1 operational current rating
- 16-22A adjustable thermal overload relay included
- TO-22 overload relay platform
- Manual and automatic overload reset options
- Class 10A overload trip characteristics
- IP44 mild steel and ABS enclosure
- CE approved
- IEC60947-4-1 compliant
Technical Details
| Brand | Switchtec |
|---|---|
| Part Number | DOL22-11-240VAC |
| Starter Rating | 22A |
| Coil Voltage | 240V |
| Motor Rating | 11kW |
| AC1 Rating | 40A |
| Overload Range | 16-22A |
| Ingress Protection | IP44 |
| Standard | IEC60947-4-1 |
Motor Control Application
This starter is suited to direct-on-line control where the selected 240V coil voltage matches the control circuit and the 16-22A overload range suits the connected motor. The included overload relay gives adjustable protection and supports both manual and automatic reset modes for flexible installation and maintenance.
