DIN Rail 24V DC Power Supply for DIN-LINK
RAKO DIN-PSU-100 DIN-LINK power supply is a DIN rail-mounted power supply unit designed to power the DIN-LINK module for RAKO Wired Network systems.
The DIN-PSU-100 features dedicated mains input and DC output terminals, along with a built-in DC LED indicator that gives visual confirmation of power output status. Its DIN rail mounting allows quick and secure installation in suitable control enclosures.
RAKO DIN-PSU-100 DIN-LINK Power Supply
The unit provides a 24V DC output and is intended for use with the RAKO DIN-LINK communication module. It is suitable for professional RAKO DIN system installations where a dedicated DIN rail-mounted power supply is required.
Key Features – RAKO DIN-PSU-100 DIN-LINK Power Supply
- DIN rail-mounted power supply for RAKO DIN-LINK
- Provides 24V DC output
- Maximum output power of 90W
- Maximum output current of 3A
- Designed for RAKO Wired Network systems
- Built-in DC LED indicator for output status
- Dedicated mains input and DC output terminals
- Width equal to 4 DIN modules
- RWN device capacity of 30
- Over current protection
- Over voltage protection
- Under voltage lockout
- Reverse polarity protection
- UKCA, CE and RoHS certified
Technical Specifications – RAKO DIN-PSU-100 DIN-LINK Power Supply
- Brand: RAKO
- SKU: DIN-PSU-100
- Product type: DIN-LINK power supply
- Mounting: Top Hat DIN rail to IEC/EN 60715
- Dimensions: W70 x H87.5 x D55mm
- DIN width: 4 DIN modules
- Weight: 230g
- Vertical clearance: 150mm
- Input supply voltage: 230V AC +10% / -15%
- Output voltage: 24V DC ±1%
- Maximum output power: 90W
- Maximum output current: 3A
- RWN device capacity: 30
- Input cable size: 1.0–3.0mm²
- Output cable size: 1.0–3.0mm²
- Input terminals: 2 x M2.5 screw terminal
- Output terminals: 4 x M2.5 screw terminal
- Protection: Over current protection, over voltage protection, under voltage lockout and reverse polarity protection
- Operating temperature: -30°C to +70°C
- Climate range: 5 to 95% RH, non-condensing
- Certification: RoHS, UKCA, CE
- Standards: IEC 62368-1, IEC/EN/BS EN 61010-1/-2-201, IEC 60335-1, IEC/EN/BS EN 61558-1/-2-16
Applications – RAKO DIN-PSU-100 DIN-LINK Power Supply
The RAKO DIN-PSU-100 DIN-LINK power supply is used in RAKO DIN rail control systems where the DIN-LINK module requires a dedicated 24V DC supply. It is suitable for smart lighting and wired control installations using the RAKO Wired Network.
Important Compatibility Note
The DIN-PSU-100 is designed for use with the RAKO DIN-LINK module. System design, RWN device capacity, wiring requirements and installation method should always be checked before installation. The DIN-PSU-100 should be installed by a competent installer as part of a suitable RAKO control system.
