Live Electrical LSMC4M-SP 1 Way SPD Metal Consumer Unit
The Live Electrical LSMC4M-SP 1 Way SPD Metal Consumer Unit is a compact surface-mounted distribution enclosure designed for installations requiring one usable outgoing way. Manufactured from steel with a clean white finish, it is supplied with a 100A double pole main switch and a 20/40kA Type 2 double pole surge protection device.
This four-module consumer unit provides one usable way after accommodating the factory-fitted main switch and SPD. It is supplied with a neutral cable, busbar, neutral and earth terminals, DIN rail and cable gland, providing the essential components required for a neat and efficient installation.
The IP40 metal enclosure features a lockable drop-down lid, multiple cable-entry knockouts and a raised DIN rail to improve internal cable routing. Its compact 136mm width makes it suitable for smaller domestic and light commercial installations where space is limited.
Key Features – Live Electrical LSMC4M-SP 1 Way SPD Metal Consumer Unit
- One usable outgoing way
- Four-module metal consumer unit
- Surface-mounted installation
- 100A double pole main switch
- 20/40kA Type 2 double pole surge protection device
- SPD configuration: SP140 1P+N/1
- IP40-rated steel enclosure
- Lockable drop-down metal lid
- Multiple cable-entry knockouts
- Raised DIN rail for improved cable routing
- Large, accessible internal wiring area
- White finish
Supplied Components
- 100A double pole main switch
- 20/40kA Type 2 surge protection device
- Neutral cable
- Busbar
- Neutral and earth terminals
- DIN rail
- Cable gland
Dimensions and Specifications
- Usable ways: 1
- Total modules: 4
- Width: 136mm
- Height: 270mm
- Depth: 110mm
- Ingress protection: IP40
- Main switch rating: 100A
- SPD rating: 20/40kA
- Enclosure material: Steel
- Mounting method: Surface mounted
Compact Consumer Unit with Surge Protection
The Live Electrical LSMC4M-SP combines main isolation, Type 2 surge protection and one usable outgoing way within a compact metal enclosure. Its accessible wiring space, raised DIN rail and flexible cable-entry options help simplify installation while maintaining an organised internal layout.
