Live Electrical SA120 Live Electrical 1 Pole 10kA/20kA Type 2 Surge Protective Device
Products may differ in size, colour and appearance to those shown. If you require further information please contact us directly.

Live Electrical SA120 1 Pole 10kA/20kA Type 2 SPD Surge Protective Device

SKU: SA120
5 In Stock
More available within:
Usually 2 - 3 Working Days
Read More

The SA120 SPD is a single-pole Type 2 device designed to protect individual circuits in residential or small commercial systems. With 10kA/20kA surge protection and BS EN compliance, it’s a compact and effective solution.

Add to wishlist
Go to the related products
Categories: ,
Tags: SPD for TN-S System, SPD for TNC-S System, SPD for TT System, Type 2 SPD
Brand:
£ 7 .95 EX VAT
£ 9 .54 IN VAT
OR
SECURE PAYMENT
We use secure checkout for safe, encrypted payments.
FREE DELIVERY
Free standard delivery on Mainland UK orders over £100.00 + VAT.
30 DAY MONEY BACK GUARANTEE
This product is covered by our 30-day money back guarantee.

Recommended for You

Single-Pole 10kA/20kA Surge Arrestor

1 Pole 10kA/20kA Type 2 SPD Surge Protective Device – Live Electrical SA120 SPD

The Live Electrical 1 Pole 10kA/20kA Type 2 SPD is a compact, single-pole Type 2 surge protection device (SPD) designed for basic circuit protection in small installations. It delivers reliable defence against power surges caused by switching operations and nearby lightning events.

Suitable for 230/380V TN-S and TT systems, this SPD is ideal for protecting lighting circuits, sensitive electronics, and small panel setups. It is fully compliant with BS EN 61643-11 and provides an excellent balance of performance and affordability.

⚙️ Key Features – SA120 Type 2 SPD

  • Type 2 SPD – Protects against transient surges from switching and external faults
  • 1 Pole Design – Perfect for individual circuit protection in single-phase setups
  • Surge Capacity – 10kA nominal, 20kA maximum (8/20 μs waveform)
  • Residual Voltage – 1.2kV at 5kA; 1.3kV at nominal discharge
  • Voltage Range – 230/380V with UT withstand of 440/640V AC
  • Short-Circuit Endurance – Admissible fault current up to 25kA
  • Fuse Compatibility – Works with gG fuses up to 125A
  • Operating Temp Range – -40°C to +85°C
  • IP20 Rating – For indoor distribution board installations
  • Certified – Fully compliant with BS EN 61643-11





Brand

Live Electrical
Discharge Capacity

10kA / 20kA
Earthing System

TN-C-S, TN-S, TT
No of Poles

1P
Product Type

SPD – Surge Protection
Type of SPD

2
Voltage

230V, 400V
