FuseBox HSP20 20 Way Horizontal Consumer Unit
20 Usable Ways in a Compact 295mm-High Enclosure
The FuseBox HSP20 20 Way Horizontal Consumer Unit is a 100A main-switch single-phase distribution board from FuseBox’s horizontal power distribution range. The compact horizontal format is intended for locations where a standard-height board is difficult to accommodate, while the internal arrangement remains spacious and installer focused.
A fixed horizontal busbar runs with a raised and removable DIN rail to improve access during cable dressing and final termination. Aligned earth and neutral bars support a tidy wiring layout, while the reversible door can be fitted to either side to suit the installation position.
Key Features
- 20 usable ways
- 100A main switch included
- Compact 295mm-high horizontal format
- Fixed horizontal busbar
- Raised and removable DIN rail
- Aligned earth and neutral bars
- Spacious internal layout for cable routing
- Reversible door for flexible positioning
- Coin-slot door lock
- No knockouts for flexible gland positioning
- Robust 1.2mm steel enclosure
- SPD-equipped alternatives available within the horizontal range
- 5-year FuseBox guarantee
Installer-Friendly Horizontal Distribution
The range also includes horizontal versions with Type 2 surge protection where an SPD-equipped board is required. The enclosure has no factory knockouts, giving the installer greater freedom when deciding cable-entry and gland positions. Devices are designed to be easily removable, and the raised DIN rail improves working access behind and around the protective devices.
The FuseBox HSP20 20 Way Horizontal Consumer Unit is part of our dedicated FuseBox Horizontal Distribution Boards range. You can also compare alternative sizes and configurations within our wider FuseBox consumer unit category.
Designed for Restricted-Height Installations
The combination of a low external profile and a generous internal layout is the key advantage of this horizontal FuseBox design. With 20 usable ways, a 100A main switch and FuseBox’s practical wiring features, the FuseBox HSP20 20 Way Horizontal Consumer Unit gives installers a compact board without turning cable termination into a cramped job.
