Description
FuseBox AEV32ABDGYZ IP65 EV Charger Consumer Unit
FuseBox AEV32ABDGYZ IP65 EV Charger Consumer Unit is a dedicated EV charger supply unit supplied with a 100A main switch, 32A Type A bi-directional RCBO and Type 2 surge protection device.
The FuseBox AEV32ABDGYZ IP65 EV Charger Consumer Unit is housed in a grey metal IP65 enclosure, making it suitable for internal or external EV charger supply installations where additional protection against dust and water ingress is required.
New model note: AEV32ABDGYZ is the updated model with a single-module SPD arrangement. It is supplied with a 32A Type A bi-directional RCBO and Type 2 surge protection. Unlike the previous version, the SPD does not require a separate MCB, so no separate 32A MCB is supplied with this model.
Key Features – FuseBox AEV32ABDGYZ IP65 EV Charger Consumer Unit
- SKU: AEV32ABDGYZ
- IP65 EV charger consumer unit
- Grey metal IP65 enclosure
- 100A main switch incomer included
- 32A Type A bi-directional RCBO included
- Type 2 surge protection device included
- No separate 32A MCB supplied with this updated model
- Suitable for dedicated 32A EV charger supply circuits
- Designed for internal and external use
- Earth and neutral terminal bars positioned at the top
- Removable and raised DIN rail for easier installation
- Round knockouts on all faces for flexible cable entry
- Identification label pack included
- Captive front cover screws for easier access and maintenance
- Tail clamp can be installed in two positions depending on configuration
Typical Uses
- Dedicated 32A EV charger supply installations
- Outdoor EV charger consumer unit applications
- Garages, sheds and outbuildings
- Domestic and light commercial EV charger supplies
- Installations requiring IP65 protection and Type 2 surge protection
Technical Details
- Part number: AEV32ABDGYZ
- Rating: 32A
- Main switch: 100A
- RCBO: 32A Type A bi-directional RCBO
- Surge protection: Type 2 SPD
- Enclosure rating: IP65
- Enclosure type: metal
- Enclosure colour: grey
- Dimensions: 270mm x 182mm x 103mm
- Application: internal and external EV charger supply installations
FuseBox EV Charger Consumer Units
The FuseBox AEV32ABDGYZ is a practical choice for installers who need a dedicated EV charger consumer unit in a robust metal IP65 enclosure. The combination of 100A main switch, 32A bi-directional RCBO and Type 2 surge protection helps provide a neat, protected and clearly identified EV charger supply.
FuseBox Consumer Units and Circuit Protection
This EV charger consumer unit is part of the wider FuseBox circuit protection range. You can also browse our FuseBox consumer units or shop the full FuseBox range for compatible boards, RCBOs, MCBs, RCDs, SPDs and accessories.
