FuseBox 100A 30mA 2 Pole Type A RCD
RTA100302 – High Current 100A Type A RCD
The FuseBox 100A 30mA 2 Pole Type A RCD is a 230V residual current device intended for installations requiring a higher 100A current rating together with 30mA Type A residual current protection.
The RTA100302 is designed for use within FuseBox consumer units, modular enclosures and TPN distribution boards. It mounts onto standard 35mm DIN rail for straightforward integration into compatible assemblies.
Unlike the lower-rated versions in this group, the 100A model accepts cables up to 35mm². Its 2 pole design is also not polarity sensitive, and the load can be connected to either the top or bottom of the device.
Technical Features
- 100A rated current
- 30mA rated residual operating current
- 2 pole Type A RCD
- Rated voltage: 230V
- Frequency: 50/60Hz
- Conditional short-circuit capacity: 10kA
- IP20 rated
- Maximum cable capacity: 35mm²
- Terminal tightening torque: 2.5Nm
- 35mm DIN rail mounting
- Top or bottom load connection
- 2 pole connections are not polarity sensitive
- Complies with IEC EN 61008-1
100A RCD for FuseBox Installations
The FuseBox 100A 30mA 2 Pole Type A RCD offers a 100A current rating together with increased maximum conductor capacity of 35mm². It provides a practical solution where a 100A-rated Type A RCD is required.
