Type A Single Module 6A B Curve 30mA Arc Fault Detection Device
WCED WFD106B-030
The WCED WFD106B-030 AFDD is a 6A-rated advanced protection device designed to safeguard electrical circuits by integrating a 30mA Type A bi-directional RCBO with an Arc Fault Detection Device (AFDD). It actively monitors electrical waveforms, detecting and isolating hazardous arc faults, short circuits, overloads, and earth leakage faults. Its switched neutral function ensures complete disconnection of faulty circuits, enhancing safety in residential and commercial electrical installations.
Key Features:
- 6A Rated Current
- 30mA Type A RCBO + AFDD
- Series & Parallel Arc Fault Detection
- Short Circuit & Overload Protection
- Overvoltage Trip at 275V ±5%
- Switched Neutral
- DIN Rail Mounting
- LED Fault Indicators
Why Choose This Product?
This device is ideal for small load circuits where electrical fire prevention is critical. Its combination of a Type A RCBO and AFDD ensures compliance with BS 7671, making it a reliable solution for protecting lighting and low-power circuits.
Where Is It Required? (BS 7671:2018)
BS 7671 recommends AFDDs for circuits in buildings such as student housing, HMOs, commercial properties, and residential applications, where fire risk mitigation is essential.
