Description
Reliable Protection with WCED WAR240-030 RCD
WCED WAR240-030 2 Pole 40A 30mA Type A High Immunity RCD
The WCED WAR240-030 2 Pole 40A 30mA Type A High Immunity RCD provides dependable residual current protection for electrical installations, detecting any imbalance in the current to prevent electric shock and fire hazards. Ideal for residential and commercial applications, this RCD features high immunity, making it suitable for sensitive systems such as Solar PV and EV charging. With a rated breaking capacity of 6kA and rapid tripping under fault conditions, the WAR240-030 ensures safe and efficient operation.
Key Features – WCED WAR240-030 2 Pole 40A RCD
- Rated Current: 40A, providing reliable protection for moderate-capacity circuits.
- Type A Design: Protects against both AC and pulsating DC residual currents.
- High Immunity: Suitable for Solar PV and EV installations.
- Rated Sensitivity: 30mA, ideal for preventing electrical shocks and fire risks.
- Break Time: Trips in ≤0.1s under I∆n for rapid fault response.
- Rated Breaking Capacity: 6kA, providing enhanced safety.
- Electrical Life: 2000 cycles, ensuring long-term reliability.
- Mechanical Life: 2000 cycles for durability.
- Installation: Easy mounting on DIN rail EN 60715 (35mm).
️ Technical Overview – WCED WAR240-030 2 Pole RCD
- Voltage: Rated for 230V (2 Pole).
- Frequency: 50/60Hz, suitable for standard electrical systems.
- Protection Degree: IP20, suitable for indoor use with protection against solid objects.
- Ambient Temperature: Operates between -5°C and +40°C, with storage from -25°C to +70°C.
- Terminal Size: Suitable for cable connections from 25mm² to 35mm².
- Mounting: Can be mounted on DIN rail (35mm).
Why Choose This Product?
The WCED WAR240-030 provides reliable protection with high immunity, making it perfect for sensitive installations like Solar PV systems and EV chargers. Its fast trip time and 6kA breaking capacity ensure safe, efficient operation in residential and commercial environments.
Guarantee & Compliance
This product complies with IEC61008-1 and BS EN61008-1 standards, guaranteeing quality and safety. It is backed by a 2-year warranty for peace of mind.
