Live Electrical SA220 2 Pole 10kA/20kA Type 2 SPD Surge Protective Device

SKU: SA220
8 In stock
More available within 1-3 working days*
Confirm Availability

Live Electrical SA220 is a 2 Pole Type 2 SPD for 230V TN-S and TT systems. With 10kA/20kA surge protection and BS EN 61643-11 compliance, it’s a compact solution for protecting homes and light commercial installations.

£15.95 + VAT

(incl. VAT £19.14)

Description

2 Pole Double Module SPD for Single-Phase Installations

10kA/20kA Type 2 SPD Surge Protective Device

The Live Electrical 2 Pole 10kA/20kA Type 2 SPD is a compact and reliable Type 2 surge protective device (SPD) for single-phase installations. It provides essential protection against transient voltages caused by indirect lightning strikes and switching events. This 2-pole SPD is ideal for small homes, offices, and light commercial setups.

With a 10kA nominal and 20kA maximum discharge capacity, the SA220 ensures your installation remains compliant with BS EN 61643-11 while reducing the risk of costly equipment damage.


⚙️ Key Features – SA220 Type 2 SPD

  • Type 2 SPD – Protects against surges from internal switching or external faults
  • 2 Pole Design – Suited for 230/380V TN-S and TT system installations
  • Discharge Capacity – 10kA nominal, 20kA maximum (8/20 μs waveform)
  • Protection Levels – ≤1.2kV residual at 5kA; ≤1.3kV at 10kA
  • Temporary Overvoltage (UT) – 440/640V AC rating
  • Admissible Short-Circuit – 25kA
  • Fuse Rating – Supports up to 125A gG fuse
  • BS EN 61643-11 Compliant – Fully certified and safe
  • IP Rating – IP20 for indoor use
  • Operating Range – -40°C to +85°C

📝 Summary – Type 2 Surge Protector 230V

The Live Electrical 2 Pole 10kA/20kA Type 2 SPD is a basic SPD for single-phase installations. With 10kA/20kA discharge capacity and BS EN 61643-11 compliance, it’s a reliable and compact solution for surge protection in smaller electrical systems.


Discover more categories from Live Electrical

Experience the quality and reliability of Live Electrical across all your electrical needs.

Additional information

Type of SPD

2

No of Poles

2P

Voltage

230V

Discharge Capacity

10kA / 20kA

Brand

Live Electrical

Product

SPD – Surge Protection

Earthing System

TT, TN-S
