Live Electrical RNC32C-30N – C32A Double Pole Single Module RCBO

Description

Compact Twin-Pole RCBO for Space-Limited Installs

32A Double Pole Single Module RCBO for Lighting & PV Protection

The RNC32C-30N is a compact 32A Curve C DP Single Module RCBO designed for precise circuit protection. This compact twin-pole RCBO with 30mA sensitivity is ideal for modern boards requiring efficient, space-saving safety components. Rated at 30mA, this single-module device delivers reliable disconnection in the event of overloads, short circuits, or earth faults. With a C Curve tripping characteristic, it suits residential and commercial installations where fast response and space-saving design are essential.

This DP RCBO is ideal for installers seeking dependable Type A protection for lighting or small power circuits. Because it is fully bi-directional, it can also be used for circuits connected to solar panels, making it suitable for PV installations. It supports bidirectional operation and ensures full compliance with BS EN 61009-1, making it a smart choice for modern electrical boards.

Key Features of the Live Electrical RNC32C-30N

• Type A RCBO – Protects against AC and pulsating DC residual currents
• C Curve Tripping – Suitable for residential and light commercial applications
• 30mA Sensitivity – Ensures rapid disconnection during earth leakage
• Single Module Width – Space-saving DP RCBO design
• 32A Current Rating – Ideal for lighting circuits and low-demand loads
• Fully Compliant – BS EN 61009-1 certified
• Fault Current Rating: 6kA

Technical Overview – 32A Curve C DP Single Module RCBO

• Product Code: RNC32C-30N
• Current Rating: 32A
• Tripping Curve: C
• Residual Current Sensitivity: 30mA
• Pole Configuration: 2P (Double Pole)
• Module Width: 1
• Breaking Capacity: 6kA
• Residual Current Type: Type A
• Bi-directional: Yes
• Standard: BS EN 61009-1
• Fault Current Rating: 6kA

What’s Included

• 1 x RNC32C-30N Double Pole RCBO (DP RCBO Single Module)
• Fault Current Rating: 6kA

Note: Busbar not included. Ensure compatibility with Live Electrical consumer units.

Why Choose This Product?

The RNC32C-30N offers a perfect blend of safety, performance, and efficiency. Its compact footprint allows more devices on the DIN rail, while Type A functionality ensures it meets the demands of today’s installations. Whether you’re upgrading a consumer unit or building from scratch, this 32A DP RCBO delivers cost-effective compliance.

Guarantee & Compliance

All Live Electrical Mini RCBOs are manufactured to meet rigorous UK standards. The RNC32C-30N is BS EN 61009-1 certified, ensuring safe, long-term performance under typical operating conditions.

Summary of the Live Electrical RNC32C-30N – 32A Curve C DP Single Module RCBO

The RNC32C-30N 32A Double Pole RCBO is a compact, single-module Type A protection device tailored for modern electrical systems. With 30mA sensitivity, C Curve response, and full compliance to BS EN standards, it’s the smart choice for reliable lighting circuit protection.

This DP RCBO Single Module is ideal for anyone needing robust protection in a space-saving form, ensuring peace of mind across residential and light commercial installs.
