32A gPV Fuse for High-Current 1500V Solar Systems
1500V DC Photovoltaic Fuse – Live Electrical PV-FU32A15 32A 20kA 10×85
The Live Electrical 32A 10×85 1500V DC Photovoltaic Fuse for solar installations is built for high-current PV string protection in extended-voltage DC applications.
This gPV-class 10x85mm fuse is rated to safely interrupt fault currents up to 20kA, providing critical protection in 1500V solar systems. It is ideal for use in commercial, utility-scale, and large rooftop PV arrays using high-capacity strings.
Key Features – 32A 10×85 1500V DC Photovoltaic Fuse
- Rated Current: 32A
- Rated Voltage: 1500VDC
- Breaking Capacity: 20kA
- Size: 10x85mm
- Function Class: gPV
- Application: High-current DC string protection in solar PV systems
- Brand: Live Electrical – advanced PV protection technology
Technical Overview
Engineered to IEC/EN60269-6 standards, this fuse is designed for dependable performance in solar environments with elevated current demands. The ceramic construction and silver-plated contacts ensure high thermal endurance and stable conductivity.
- Product Code: PV-FU32A15
- Standards: IEC/EN60269-6 compliant
- Design: Cylindrical ceramic fuse body
- Ends: Silver-plated terminals for secure fuse holder contact
- Compatibility: Works with 10x85mm 1500VDC fuse holders
What’s Included
- 1 x Live Electrical PV-FU32A15 Photovoltaic Fuse (32A, gPV, 1500VDC)
Why Choose This Product?
This 32A 1500V solar fuse provides outstanding protection for high-load PV arrays. Its high breaking capacity and voltage rating make it ideal for advanced installations requiring fuse protection for 1500VDC solar power systems.
Guarantee & Compliance
Compliant with IEC/EN60269-6 and tested for use in solar-specific applications. Trusted by installers and system designers for long-term reliability in high-voltage photovoltaic systems.
Summary – 32A 10×85 1500V DC Photovoltaic Fuse
The Live Electrical 32A 1500VDC photovoltaic fuse in 10x85mm size delivers high-current, gPV-rated protection for modern solar PV arrays. Designed for 1500VDC installations with a 20kA fault interruption capacity.
