20A Solar PV Circuit Protection with gPV Rating
Live Electrical PV-FU20A10 20A 20kA 10×38 1000V DC Photovoltaic Fuse
The Live Electrical 20A 10×38 1000V DC Photovoltaic Fuse for solar systems provides critical overcurrent protection for PV strings.
This 10x38mm gPV-class fuse is rated at a robust 20kA breaking capacity, making it ideal for high-voltage solar applications. Designed to fit standard 10×38 photovoltaic fuse holders, it ensures consistent and safe protection in residential, commercial, and industrial PV installations.
Key Features – 20A 10×38 1000V DC Photovoltaic Fuse
- Rated Current: 20A
- Rated Voltage: 1000VDC
- Size: 10x38mm
- Breaking Capacity: 20kA
- Function Class: gPV
- Application: Solar DC circuit protection
- Brand: Live Electrical – performance-built solar solutions
Technical Overview
The PV-FU20A10 fuse supports safe fault interruption in PV string circuits. Its compact cylindrical design is fully compatible with holders like the PV32-1085 and PV32-1038X, offering easy installation and long-term reliability.
- Product Code: PV-FU20A10
- Body Type: High-strength ceramic
- Contact Finish: Silver-plated ends for secure conductivity
- Standards: Complies with IEC/EN60269-6
- Compatibility: Fits 10x38mm DC fuse holders
What’s Included
- 1 x Live Electrical PV-FU20A10 Photovoltaic Fuse (20A, gPV, 1000VDC)
Why Choose This Product?
Built for modern solar systems, this DC fuse for PV string protection is a safe and compact solution for managing fault currents. It is ideal for solar installations requiring 20A fuse protection, especially when space-saving 10x38mm fuses are specified.
Guarantee & Compliance
Live Electrical fuses are built to exacting international standards, including IEC/EN60269-6 for photovoltaic circuit protection. Trusted by professionals for safe, dependable solar integration.
Summary – 20A 10×38 1000V DC Photovoltaic Fuse
The Live Electrical 20A 1000VDC photovoltaic fuse offers reliable gPV-class protection for solar arrays. Its 10x38mm format and 20kA capacity make it a compact, high-performance choice for PV string safety.
