20A D Curve MCB Miniature Circuit Breaker – 10kA
Live Electrical CB120D Single Pole MCB
The Live Electrical 20 Amp Miniature Circuit Breaker (MCB) provides reliable protection with a 10,000A breaking capacity. This Type D MCB is specifically designed for circuits with high inrush currents, such as motors and transformers, tripping between 10 to 20 times the start-up current.
Operating at a voltage rating of 230-400V, this MCB offers an electrical endurance of 20,000 operations, making it ideal for commercial and industrial installations where reliable circuit protection is crucial.
With its compact size (81mm x 17.5mm x 73mm), it fits easily into Live Electrical Consumer Units and Live Electrical TPN Three Phase Distribution Boards. Pairing this MCB with Live Electrical Consumer Units ensures full compliance with BS7671 standards, providing enhanced safety and protection for your electrical systems.
Key Features:
- Breaking capacity: 10kA
- Voltage rating: 230-400V
- Current rating: 20A
- Electrical endurance: 20,000 operations
- Compact dimensions: 81mm x 17.5mm x 73mm
- Designed for use with Live Electrical Consumer Units
Ensure reliable protection for your circuits with the Live Electrical 20A MCB, available now at Electrical4Less. This MCB is part of a comprehensive range of MCBs and RCBOs, providing high-quality solutions at competitive prices.
For enhanced protection, pair this MCB with Live Electrical Consumer Units or Live Electrical SPD Consumer Units, ensuring full compliance with BS7671 standards.
