Description
Reliable Circuit Protection, Suitable for EV and Renewable Energy
AMR106C-030 – Live Electrical AMR106C-030 30mA Type A 6A 6kA C Curve Bi-Directional RCBO
The AMR106C-030 provides combined overload, short-circuit, and 30mA earth-leakage protection in a compact 1P+N format. With C Curve tripping and a 6kA breaking capacity, it is designed for circuits with higher inrush currents such as lighting, HVAC, and motor-driven loads.
The switched neutral ensures only the faulty circuit is disconnected, maintaining supply to healthy circuits. Its bi-directional design makes it suitable for PV solar and renewable energy systems where current may flow in either direction. Fully compliant with BS EN 61009-1, it delivers trusted performance for domestic, commercial, and industrial setups.
Key Features – Live Electrical 6A C Curve Bi-Directional RCBO
- Rated current: 6A – ideal for matching circuit loads
- 30mA Type A protection – detects AC and pulsating DC leakage
- C Curve tripping – suited for inductive or high inrush loads
- Breaking capacity: 6kA (Icn)
- Switched neutral – isolates only the faulty circuit
- Bi-directional – PV and renewable energy compatible
- Compact single-module design (1P+N) – saves space
- Voltage: 230V AC
- Electrical endurance: 4,000 cycles; Mechanical: 100,000 cycles
- Complies with BS EN 61009-1
Why Choose This Live Electrical Bi-Directional RCBO?
This RCBO is perfect for lighting and control circuits where inrush currents may occur. It delivers reliable, compact, and regulation-compliant protection for installers.
