Description
Live Electrical 10A 1000V DC Solar Photovoltaic Diode Connector
Solar Photovoltaic 10A Diode Connector
Live Electrical 10A 1000V DC Solar Photovoltaic Diode Connector is designed to control current flow and protect photovoltaic systems from reverse current conditions. Commonly used within PV arrays, it helps safeguard solar modules and connected equipment, supporting system safety and long-term reliability.
Rated at 1000V DC with a current capacity of 10A, the connector is suitable for residential and commercial solar installations. Tin-plated copper contacts ensure excellent electrical conductivity and low contact resistance, supporting efficient performance under continuous operation.
The robust PPO insulation housing provides strong electrical insulation and mechanical durability, while the IP67 ingress protection rating ensures dependable operation in outdoor environments exposed to moisture and dust. Manufactured to IEC 62852 standards, this diode connector meets recognised industry requirements for solar photovoltaic applications.
Key Features – Solar Photovoltaic 10A Diode Connector
- Solar photovoltaic diode connector
- Rated voltage: 1000V DC
- Rated current: 10A
- Prevents reverse current flow in PV systems
- IP67 protection for outdoor installations
- Low contact resistance for efficient operation
- Durable PPO insulation housing
- Suitable for residential and commercial solar systems
Technical Specification – Solar Photovoltaic 10A Diode Connector
- Rated Voltage: 1000V DC
- Rated Current: 10A
- Standard: IEC 62852
- Contact Resistance: ≤0.5 mΩ
- Contact Material: Copper, Tin Plated
- Insulation Material: PPO
- Ambient Temperature Range: -40°C to +85°C
- IP Rating: IP67
