Description
Discreet Miniature Recessed Double Door Sensor – Black
Leyton S-MINI-DS-DUO
The Leyton Discreet Miniature Recessed Double Door Sensor is an elegant and practical solution designed to enhance the functionality of your lighting system. With its sleek black finish and compact design, this sensor seamlessly integrates into your environment, providing automatic lighting control for your doors.
Key Features
- Max Load: 250W
- Compact Design: The miniature recessed sensor head ensures a low-profile installation.
- Automatic Operation: Lights are activated when the door is opened and turned off when the door is closed, providing convenience and energy efficiency.
- Detection Range: Effective within a range of 100mm, ensuring reliable performance.
- Finish: Sleek black, suitable for various decor styles.
- Voltage: Operates on a standard 240V power supply.
- Wattage: Supports up to 250W, accommodating a wide range of lighting solutions.
- IP Rating: IP20, indicating protection against solid objects up to 12mm and no protection against liquids.
- Dimensions: The main body measures 76x35x19mm, while the sensor head has a diameter of 10mm and a depth of 13mm.
- Cut Out Size: Requires an 8mm cut out for installation.
- Class II: Double insulated, ensuring safety and compliance with electrical standards.
Technical Specifications
- Finish: Black
- Voltage: 240V
- Wattage: 250W
- IP Rating: IP20
- Dimensions (LxWxD): 76x35x19mm
- Head Dimensions: 10mm diameter x 13mm depth
- Cut Out: 8mm
- Class: II
Applications
Ideal for use in cabinets, wardrobes, and other door-activated lighting scenarios, the Leyton Discreet Miniature Recessed Double Door Sensor provides a sleek and efficient solution for modern lighting needs.
