Accurate Multi-Directional Energy Monitoring for Commercial and Industrial Use
IM3D-100A Three Phase MID Approved Meter
The IM3D-100A MID Approved 3 Phase Electricity Meter is a reliable, direct-connected meter for energy monitoring. It works well in solar PV setups, commercial spaces, and light industry. This meter tracks both import and export energy with 4-quadrant measurement. It also includes pulse outputs and a large, clear LCD screen for easy reading.
Key Features – IM3D-100A Three Phase Energy Meter
- MID Approved for billing compliance (Class B active, Class 2 reactive)
- 4-Quadrant Energy Measurement – Import/export, active/reactive energy tracking
- Optional Power Quality Readings – Volts, current, and power*
- Configurable Pulse Outputs – Ideal for energy management and AMR systems
- Optical Communications Port – Enables remote data collection
- 8-Digit LCD – Clear energy readout with intuitive symbols
- Solid Brass Terminals – High-quality construction for lasting reliability
- Optional Terminal Covers – Short, standard, or extended plus
- IP54 Rated Enclosure – Suitable for a wide range of environments
⚙️ Technical Specifications
- Voltage: 3 × 230V (400V withstand)
- Frequency: 50Hz ± 5%
- Current: Up to 100A (Imax)
- Accuracy: Class B (EN 50470-1/3), Class 2 (IEC 62053-23)
- Ingress Protection: IP54 (EN 60529)
- Temperature Range: –25°C to +55°C
- Terminal Arrangement: DIN43857 Part 2, 150mm centers
- Pulse Output Standard: kWh import (AV variant)
Applications
- Commercial buildings
- Light industrial sites
- Solar PV systems (import/export monitoring)
- Tenant submetering
Summary – IM3D-100A MID Approved 3 Phase Meter
The IM3D-100A offers smart energy tracking for three-phase systems. It combines billing compliance, 4-quadrant tracking, and strong build quality. With pulse outputs and a clear LCD, it supports accurate billing and energy management in commercial or solar installs.
