Advanced 3-Phase Electricity Meter with Import/Export Tracking and Solid Brass Terminals
IM3D-100A-NET MID Approved Three Phase Energy Meter with NET Parameter
The IM3D-100A-NET Three Phase MID Meter is built for accurate tracking of both imported and exported energy. Thanks to the NET parameter, it calculates the net difference between what is consumed and what is exported—ideal for solar PV, submetering, and commercial monitoring. It is MID approved for billing use and includes solid brass terminals, a clear LCD, and pulse outputs for external systems.
Key Features – IM3D-100A-NET NET-Enabled MID Meter
- MID Approved – Certified for billing with Class B accuracy
- NET Parameter – Calculates net energy use (import minus export)
- 4-Quadrant Measurement – Tracks active and reactive energy flow
- Pulse Outputs – For connection to AMR, BMS, or data loggers
- LCD Display – 8-digit screen with import/export icons
- Brass Terminals – Secure and reliable connections for high-current circuits
- DIN Rail Mountable – Easy installation and optional terminal covers
- IP54 Housing – Suitable for indoor and protected outdoor use
⚙️ Technical Summary
- Voltage: 3 × 230V
- Frequency: 50Hz
- Current Range: 0.5A – 100A
- Accuracy: Class B (EN50470), Class 2 (IEC 62053)
- Temperature Range: –25°C to +55°C
- Pulse Output: Configurable for active/reactive energy
- Display: LCD, 8-digit with NET indication
- Protection: IP54
Suitable Applications – Three Phase Energy Meter with NET Parameter
- Solar PV systems – Measure net generation and usage
- Tenant billing – Use in commercial and residential submetering
- Industrial sites – Track real-time energy balance
- Utility setups – Approved for accurate energy billing
Summary – Three Phase MID Meter with NET Energy Tracking
The IM3D-100A-NET is a smart 3-phase MID meter that supports net metering. With billing approval, 4-quadrant measurement, and pulse output, it’s a top choice for solar, commercial, and submetering setups. The NET parameter helps monitor energy efficiency and export.
