Single-Module Surge Protection for Hager Consumer Units
Hager VMES02SPD
TheHager VMES02SPD Consumer Unit SPD is a compact single-module Type 2 surge protection device designed specifically for Hager consumer units. It mounts directly on the busbar, can be installed in any outgoing position on a compatible 100A RCBO main switch board, and requires no separate backup MCB, saving valuable space and installation time while helping domestic installations meet BS 7671 18th Edition requirements.
Key Features – Hager VMES02SPD Consumer Unit SPD
- Single-module (17.5 mm) Type 2 consumer unit SPD for Hager boards.
- Busbar-mounted design, saving space and reducing installation time.
- No additional backup MCB required, simplifying wiring and lowering cost.
- Pluggable surge protection cartridge (replacement ref: SPL013Z) for easy, tool-free changeover.
- Optical status indication: green = healthy, red = replace.
- CT2 connection compliant with BS 7671 18th Edition (Section 534).
- Compatible with TN-C-S (PME), TN-S and TT earthing arrangements.
- Rated voltage Ue: 230 V, continuous operating voltage Uc: 275 V.
- In nominal discharge current: 20 kA, Imax discharge current: 40 kA.
- Operating temperature range: −40 °C to +60 °C.
- Dimensions: 84 mm (H) × 17.5 mm (W) × 74 mm (D).
- EAN: 3250610138403.
Applications – Hager VMES02SPD Consumer Unit SPD
- New Hager consumer unit installations requiring compliant surge protection.
- Retrofit SPD upgrades in existing 100A RCBO main switch consumer units.
- Properties adding EV chargers, PV solar, battery storage or heat pumps.
- Domestic protection for sensitive electronics, smart-home systems and appliances.
- Use alongside the full range of Hager Consumer Units
Compatibility & Installation Notes
- Designed for Hager single-phase residential consumer units; fit on the high-integrity side of
a dual RCD consumer unit where applicable. - Line connection is via the busbar; neutral and earth are connected using 6 mm² cable links
to the neutral and earth bars. - Suitable for CT2 connection as per BS 7671 18th Edition, Section 534.
- Unplug the SPD cartridge before performing insulation resistance testing to avoid inaccurate readings.
- Installation must be carried out by a suitably qualified and competent electrician in accordance
with current wiring regulations.
Related Hager Products
- Browse all Hager Consumer Units for compatible boards.
- View the full Hager SPD range including other Type 2 surge protection options.
