Description
1P+N 25A 30mA F Class RCCB
Hager CDF525U
The Hager CDF525U is a 1P+N RCCB designed with 25A rated current and 30mA residual operating current, providing F Class functionality. This RCCB ensures advanced protection by detecting AC and mixed-frequency residual currents, making it suitable for residential, commercial, and industrial installations. Moreover, its compact design and short-time delayed tripping enhance safety and reliability in multi-device setups.
Detailed Features and Functionality
The Hager CDF525U combines precise fault detection with compact dimensions, making it ideal for modern electrical systems. Furthermore, its F Class capability allows it to detect AC and mixed-frequency residual currents, ensuring comprehensive protection in circuits that include variable frequency drives and electronic devices. Additionally, the short-time delayed tripping feature guarantees selectivity in systems with multiple protective devices, enhancing overall reliability.
This RCCB operates at a rated voltage of 230V AC, with a maximum operating voltage of 253V and a rated impulse withstand voltage of 4000V. Its 25A rated current and 30mA residual operating current ensure reliable protection for low-load circuits.
Built to last, the RCCB features electrical endurance of 10,000 cycles and mechanical endurance of 20,000 operations. Its dimensions—70mm depth, 85mm height, and 36mm width—make installation straightforward, even in tight spaces. Moreover, it operates reliably in temperatures ranging from -25°C to 70°C, ensuring suitability for various conditions.
Key Features of Hager CDF525U
- 1P+N Configuration: Suitable for single-phase systems.
- Rated Current: 25A for low-load circuits.
- Residual Operating Current: 30mA for sensitive fault detection.
- F Class Functionality: Detects AC and mixed-frequency residual currents for advanced safety.
- Short-Time Delayed Tripping: Ensures reliable performance in multi-device setups.
- Voltage Ratings: Operates at 230V with a max voltage of 253V and 4000V impulse withstand.
- High Endurance: Performs 10,000 electrical cycles and 20,000 mechanical operations.
- Compact Design: 36mm width for efficient space usage.
- Compliant Standards: Meets EN 61008-1 safety requirements.
