Smart Mesh-Controlled Distribution for Loox5 Lighting Systems
2-Way Distributor, 24V, Tuneable White with Bluetooth – Häfele 850.00.846
The Häfele 850.00.846 Loox5 2-Way Distributor with Connect Mesh is a smart and powerful control module designed for multi-white lighting setups. It enables wireless Bluetooth control, manual switch input, and programmable light behaviour across two synchronised output ports. Part of the Loox5 24V system, it provides an easy way to control on/off, dimming (0–100%), and colour temperature changes via app or compatible switch.
Ideal for use in fitted furniture, shelves, or display installations, this module simplifies lighting control while offering flexible integration. With its slim profile and soft colour-change transitions, it’s a perfect solution for modern home and commercial interiors using tuneable white LED lighting.
Key Features of the Häfele 850.00.846 Loox5 2-Way Distributor
- Two output ports (Loox5 3-pin MW 24V), synchronised
- Programmable Bluetooth control via Connect Mesh app (iOS® / Android™)
- Optional manual control input for Loox switches and sensors
- Colour temperature pre-selection with 4 options: 2700K / 3000K / 4000K / 5000K
- On/off switching, dimming (0–100%) and smooth white light colour transition
- Easily switch from Bluetooth mode to manual switching mode
- Connect multiple units for mesh signal amplification
- Low voltage input: Loox5 2-pin 24V box-to-box
- Max power load: 120W total
- Max network range: 5m (clear line of sight)
- Includes: 1x 2-way distributor
- Dimensions: 115 x 50 x 16 mm
- Colour/finish: Black plastic housing
- Mounting: Screw fixing or secure enclosure fit
- Indoor use only (IP20)
Application Notes
- Use only with Loox5 24V multi-white (MW) components
- Connect to the 7th continuous output if used with a 6-way distributor
- Maximum cable distance from driver to distributor: 2 metres
- Mesh network range may reduce due to obstructions or interference
- Additional Connect Mesh modules act as range amplifiers
- When in wired mode, colour selection must be set using onboard function button
- Ideal for bedroom cabinetry, kitchen units, or commercial furniture lighting
Summary of the Häfele 850.00.846 Loox5 Mesh 2-Way Distributor
The Häfele 850.00.846 Loox5 2-Way Distributor with Bluetooth Mesh is built to simplify and modernise your tuneable white lighting system. With two synchronised outputs and smooth switching between Bluetooth and wired control, it offers unmatched flexibility.
Whether you’re using the app to schedule lighting changes or installing a manual Loox switch, this distributor gives you full control. Additionally, the compact design and smart mesh connectivity make it easy to integrate into tight or hidden spaces. It’s a future-ready upgrade that reduces wiring while improving user experience. Backed by Häfele’s Lifetime Guarantee, it’s a smart choice for both home and commercial lighting control.
Guarantee & Compliance
This product is covered by the Häfele Lifetime Guarantee for domestic use. All components are tested to meet stringent internal standards and relevant industry certifications.
For commercial use, a 12-month standard guarantee applies. For full details, visit Hafele Website.
