32A 3P+N+E 5 Pin Plug – 380–415V – Straight Connector
Gewiss GW62020H 32A 5 Pin Plug – IP44/IP54 – Screw Wiring – Red – IEC 309 HP Range
The Gewiss GW62020H is a 32A straight industrial connector (5 pin plug, 3P+N+E) designed for robust three-phase power connections in demanding environments. Supporting 380–415V systems, it ensures safe, durable, and efficient energy distribution across industrial and commercial applications.
Built from halogen-free materials and compliant with IEC 60309 standards, this plug offers IP44/IP54 protection, IK09 impact resistance, and surface-treated nickel-plated contacts to prevent corrosion. Its screw terminal design and integrated cable clamp (tightening range: 9.2–19.9 mm) support a secure and easy connection.
⚙️ Key Features of the Gewiss GW62020H 32A 5 Pin Plug
- Rated Current: 32A
- Poles: 3P+N+E (5 pin plug)
- Rated Voltage: 380–415V
- Frequency: 50/60 Hz
- Connector Type: Straight mobile plug
- Ingress Protection: IP44/IP54 – for dust and splash protection
- Mechanical Resistance: IK09 – high impact resistance
- Color: Red
- Hour Reference: 6H
- Wiring Type: Screw terminals
- Cable Compatibility:
- Flexible: 2.5–6 mm²
- Rigid: 2.5–10 mm²
- Cable Clamp Range: 9.2–19.9 mm
- Material: Halogen-free (EN 60754-2 compliant)
- Glow Wire Test: 850°C (active), 650°C (passive)
- Thermo-pressure with Ball: 125°C (active), 80°C (passive)
- Operating Temperature: -25°C to +55°C
- Insulation Resistance: > 10 MΩ
- Permissible Overload: 42A
- Breaking Capacity at 1.1 Un: 40A
- Lifespan: > 2000 operations
✅ Why Choose Gewiss GW62020H?
The Gewiss GW62020H straight connector is a professional-grade 5 pin plug solution engineered for mobility, safety, and ease of use. Its solid construction, nickel-plated contacts, and reliable cable grip system ensure secure operation in all conditions. With IP44/IP54 sealing, it’s perfect for use in semi-protected or industrial areas requiring robust power connections.
Ideal Use Cases
- Portable three-phase machinery
- Industrial equipment power supply
- Temporary site power distribution
- Commercial power tools and systems
- Generator or mobile power hook-ups
❓ Frequently Asked Questions (FAQs)
- Q: Is this a 5 pin plug?
A: Yes, it’s a 3P+N+E configuration—commonly referred to as a 5 pin plug for three-phase use. - Q: Is it a mobile straight connector?
A: Yes, it’s a straight plug designed for portable connections. - Q: Can this plug handle outdoor conditions?
A: It has IP44/IP54 ratings, suitable for indoor and semi-protected outdoor environments. - Q: What cable sizes can it handle?
A: It supports 2.5–6 mm² flexible and 2.5–10 mm² rigid cables, with clamp range of 9.2–19.9 mm. - Q: Is it heat and impact resistant?
A: Yes, with glow wire resistance up to 850°C and IK09 mechanical resistance.
Summary of the Gewiss GW62020H 32A 5 Pin Plug
The Gewiss GW62020H is a 32A straight 5 pin plug (3P+N+E) ideal for mobile or temporary three-phase connections in industrial environments. Built to IEC 60309 standards, it offers IP44/IP54 ingress protection, halogen-free construction, and IK09-rated mechanical durability. With screw terminals and a secure cable clamp, it supports fast installation, making it perfect for workshops, generators, and temporary power setups.
