32A 2P+E 3 Pin Plug – 100–130V (110V Class) – Straight Connector
Gewiss GW62012H 110V 3 Pin Plug – IP44/IP54 – Screw Wiring – Yellow – IEC 309 HP Range
The Gewiss GW62012H is a 32A straight industrial connector (3 pin plug, 2P+E) built for 100–130V (commonly used as 110V) power systems in temporary and industrial installations.
It ensures secure and durable connections with IP44/IP54 ingress protection, IK09 impact resistance, and nickel-plated contacts for extended corrosion protection.
This yellow straight plug is part of the IEC 309 HP range, compliant with international IEC 60309 standards, and made from halogen-free materials. Featuring screw terminal wiring and a wide-range cable clamp, it’s designed for reliable use in high-demand settings like site equipment, portable machinery, and industrial maintenance tools.
⚙️ Key Features of the Gewiss GW62012H 110V 3 Pin Plug
- Rated Current: 32A
- Poles: 2P+E (3 pin plug)
- Rated Voltage: 100–130V (110V socket class)
- Frequency: 50/60 Hz
- Connector Type: Straight plug
- Ingress Protection: IP44/IP54 – splash-resistant and dust-resistant
- Mechanical Resistance: IK09 – high impact tolerance
- Color: Yellow
- Hour Reference: 4H
- Wiring Type: Screw terminal
- Cable Compatibility:
- Flexible: 2.5–6 mm²
- Rigid: 2.5–10 mm²
- Cable Clamp Range: 9.2–19.9 mm
- Material: Halogen-free (EN 60754-2 compliant)
- Glow Wire Test: 850°C (active), 650°C (passive)
- Thermo-pressure with Ball: 125°C (active), 80°C (passive)
- Operating Temperature: -25°C to +55°C
- Insulation Resistance: > 10 MΩ
- Permissible Overload: 42A
- Breaking Capacity at 1.1 Un: 40A
- Operational Lifespan: Over 2000 connections
✅ Why Choose Gewiss GW62012H 110V 3 Pin Plug?
The Gewiss GW62012H 110V straight connector is a rugged, easy-to-wire 3 pin plug for portable or mobile installations. Designed for performance and built for durability, its nickel-plated contacts and sealed IP-rated housing ensure secure operation in semi-protected environments. Whether on-site or in industrial setups, it provides reliable and standard-compliant connectivity.
Ideal Use Cases
- Construction site tools and equipment
- Temporary lighting and power setups
- Industrial generators or transformers
- Portable machines and appliances
- Commercial low-voltage power systems
❓ Frequently Asked Questions (FAQs)
- Q: Is this a 110V plug?
A: Yes, it supports 100–130V applications and is commonly used for 110V power tools and equipment. - Q: Is it a 3 pin plug?
A: Yes, the 2P+E configuration makes it a 3 pin industrial connector. - Q: What kind of cables can be used?
A: It supports flexible cables (2.5–6 mm²) and rigid cables (2.5–10 mm²). - Q: Can it be used outdoors?
A: It’s suitable for semi-protected outdoor environments with its IP44/IP54 rating. - Q: What is the yellow color and 4H for?
A: These identify the voltage rating and ensure correct plug/socket matching in 110V systems.
Summary of the Gewiss GW62012H 110V 3 Pin Plug
The Gewiss GW62012H is a 32A 2P+E straight industrial connector for 100–130V (110V class) power. Built to IEC 60309 standards, it features IP44/IP54 ingress protection, halogen-free materials, nickel-plated pins, and IK09 impact resistance. This 3 pin plug is perfect for mobile industrial equipment and temporary low-voltage power setups, offering quick screw terminal wiring and a secure cable clamp.
