32A 2P+E 3 Pin Plug – 100–130V (110V Class) – Straight Industrial Plug
🟡 Gewiss GW60012H 32A 110V Industrial Plug – IP44/IP54 – Screw Wiring – Yellow – IEC 309 HP Range
The Gewiss GW60012H is a 32A straight plug (2P+E) designed for low-voltage, 100–130V (110V) systems. It’s ideal for construction sites, temporary power setups, and portable industrial equipment.
Engineered under the IEC 309 HP range, this plug ensures compliance with IEC 60309-1 and 60309-2 standards. Its IP44/IP54 protection guards against splashes and dust, while the IK09 rating ensures excellent impact resistance. Constructed from halogen-free material, it enhances fire safety and environmental compliance.
Additionally, the nickel-plated pins prevent corrosion, and the screw-type terminals with a wide cable clamp range (9.2–19.9 mm) simplify installation. This plug delivers dependable, long-lasting performance across various mobile and fixed low-voltage applications.
⚙️ Key Features of the Gewiss GW60012H 32A 110V Industrial Plug
- Current Rating: 32A
- Pin Configuration: 2P+E (3 pin plug)
- Voltage: 100–130V (110V compatible)
- Frequency: 50/60 Hz
- Connector Type: Straight plug
- Ingress Protection: IP44/IP54
- Impact Resistance: IK09
- Color: Yellow
- Hour Reference: 4H
- Wiring System: Screw terminals
- Cable Compatibility:
- Flexible: 2.5–6 mm²
- Rigid: 2.5–10 mm²
- Clamp Range: 9.2–19.9 mm
- Material: Halogen-free (EN 60754-2 compliant)
- Thermal Ratings:
- Glow wire test: 850°C (active), 650°C (passive)
- Thermo-pressure: 125°C (active), 80°C (passive)
- Temperature Range: -25°C to +55°C
- Insulation Resistance: > 10 MΩ
- Overload Tolerance: 42A
- Breaking Capacity at 1.1 Un: 40A
- Usage Lifespan: Over 2000 operations
✅ Why Choose Gewiss GW60012H 32A 110V Industrial Plug?
If you’re managing low-voltage equipment on-site or in mobile operations, the Gewiss GW60012H is built to perform. It combines durability, easy installation, and safety in a compact format. Its distinctive yellow housing with 4H positioning ensures voltage compatibility and prevents incorrect plug-ins.
🌐 Ideal Use Cases
- 110V construction site tools
- Temporary site lighting
- Portable generators
- Low-voltage machinery
- Industrial maintenance setups
❓ Frequently Asked Questions (FAQs)
- Q: Is this a 110V plug?
A: Yes, it’s suitable for 100–130V applications and widely used for 110V systems. - Q: What is the plug configuration?
A: It is a 2P+E setup, also known as a 3 pin plug for single-phase connections. - Q: Can I use this outdoors?
A: Yes, in sheltered or semi-exposed areas, thanks to its IP44/IP54 rating. - Q: Is the wiring secure?
A: Absolutely. The screw terminals and cable clamp ensure a firm connection. - Q: What type of cable can I use?
A: It supports flexible (2.5–6 mm²) and rigid (2.5–10 mm²) cables.
Summary of the Gewiss GW60012H 32A 110V Industrial Plug
The Gewiss GW60012H is a 32A 2P+E straight plug designed for 100–130V (110V) low-voltage power. It features IP44/IP54 protection, halogen-free materials, corrosion-resistant nickel-plated pins, and a secure cable clamp. This 3 pin plug is perfect for construction sites, mobile power tools, and industrial environments where reliable and safe low-voltage power is essential.
